gate valve with handwheel series GA001; length according to EN558-1R26 housing cast steel; nominal flange pressure PN40; handwheel steel; packing gland graphite; rising stem; medium temperature -10...+400°C; pressure range 0...40bar; DN 50mm; length 250mm
Country of origin: China
Weight: 20.5 Kg
Short Itemnumber: GA00150W
gate valve with handwheel series GA001; length according to EN558-1R26 housing cast steel; nominal flange pressure PN40; handwheel steel; packing gland graphite; rising stem; medium temperature -10...+400°C; pressure range 0...40bar; DN 50mm; length 250mm
Technical specifications
| Pressure range | 0...40bar |
|---|---|
| DN | 50 mm |
| Length | 250 mm |
| Pressure range | 0...40bar |
| DN | 50 mm |
| Length | 250 mm |
GA001-50-W
Documents
German / Deutsch
Data Sheets
1-
PDF
Datenblatt · Keilrundschieber mit Handrad Serie GA001 · DE
Data sheet 1,5 MB Updated 13/06/2026
English
Data Sheets
1-
PDF
Data sheet · Gate valve with handwheel Series GA001 · EN
Data sheet 1,5 MB Updated 13/06/2026
