Butterfly valve with bare shaft Series BUL1-DSE-B, BULA-DSE-B, BULG-DSE-B, BULC-DSE-B, BULY-DSE-B; Lug type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner NBR; Medium temperature -10...+130°C; DN 250mm; Length 68mm; Pressure range 0…10bar; Nominal flange pressure PN10; Incl. Inspection certificate EN-10204-3.1; For material, pressure and tightness
Country of origin: Italy
Short Itemnumber: BULC250DSNB3C
butterfly valve with bare shaft series BUL1-DSE-B, BULA-DSE-B, BULG-DSE-B, BULC-DSE-B, BULY-DSE-B; lug type; length according to EN558−1R20; body ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner EPDM; medium temperature -10...+130°C; DN 350mm; length 78mm; pressure range 0…10bar; nominal flange pressure PN10
Technical specifications
| Pressure range | 0...10 bar |
|---|---|
| DN | 350 mm |
| Length | 78 mm |
| Flange | PN10 |
| Pressure range | 0...10 bar |
| DN | 350 mm |
| Length | 78 mm |
| Flange | PN10 |
