Ball valve with pneumatic actuator BA050-50-0H-01

Ball valve with pneumatic actuator BA050-50-0H-01

Flanged ball valve with electrical actuator; For steam; Flange PN16; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Medium temperature -20...+198°C; Pressure range Steam 0...15bar; Nominal diameter 50mm; Length 82mm; Operating time 9s; Voltage 100-240VAC; V-Ball 90°

Intrastat No.: 84818081
Country of origin: Italy Made in Europe
Short Itemnumber: BA050500H01
https://www.stasto.ro/web/image/product.template/181248/image_1920?unique=f96ddcc

flanged ball valve with electrical actuator; for steam; flange PN16; body, ball AISI 316; seals PTFE-reinforced/FKM; medium temperature -20...+198°C; pressure range steam 0...15bar; nominal diameter 50mm; length 82mm; operating time 9s; voltage 100-240VAC; V-ball 90°

999.999,00 lei 999999.0 RON 999.999,00 lei

Not Available For Sale

excl. tax
  • Brand

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Pressure range Steam 0...15bar
Brand STASTO
Pressure range Steam 0...15bar
Brand STASTO
Flanged ball valve BA050-50-L-A-01
BA050-50-L-A-01 x 1.0 Pcs
Flanged ball valve BA050-50-L-A-01
Flanged ball valve Series BA050-L-A; For steam; ATEX II 2 G/D; Fire-safe; TA-Luft; Flange PN16; Full bore; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Pressure range Steam 0...15bar; Medium temperature -20...+198°C; Nominal diameter 50mm; Length 82mm; V-Ball 90°
Electrical actuator VB060-H
VB060-H x 1.0 Pcs
Electrical actuator VB060-H
Electrical actuator Series VB; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 60Nm; Operating time 9s; Flange ISO5211 F05/F07-Stern 14 mm; Voltage 100-240VAC; Protection class IP67
RI3002 x 1.0 Pcs
RI3002
Mounting bracket, F07/F05-F05, Bolt 14-10
