Elemente de conectare și cuplaje
| Diametru | Filet exterior | Tip |
|---|---|---|
| 8/6 mm | G 1/8" | SC35-08-18-P |
| filet mama | DN | pres. | Tip |
|---|---|---|---|
| G 1" | 25 mm | 0...210 bar | CICS1-F10-S |
| Diametru | Filet exterior | Tip |
|---|---|---|
| 8/6 mm | G 1/4" | SC35-08-14-P |
conector tată blocare serie CIPS-S
în consecință ISO 7241-1 serie B; filet mama; otel inoxidabil 1.4401; sigiliu FKM; Temperatura -25...+200°C
Grundversion
| filet mama | DN | pres. | Tip | Secvență |
|---|---|---|---|---|
| G 1/4" | 6,3 mm | 0...350 bar | CIPS1/4-F14-S | 6900000 |
| G 3/8" | 10 mm | 0...270 bar | CIPS3/8-F38-S | 6900001 |
| G 1/2" | 12,5 mm | 0...320 bar | CIPS1/2-F12-S | 6900002 |
| G 3/4" | 20 mm | 0...250 bar | CIPS3/4-F34-S | 6900003 |
| G 1" | 25 mm | 0...210 bar | CIPS1-F10-S | 6900004 |
Grundversion
| Diametru | Filet exterior | Tip | Secvență |
|---|---|---|---|
| 6/4 mm | R 1/8" | SC16C-06-18-P | 6900004 |
| 6/4 mm | R 1/4" | SC16C-06-14-P | 6900005 |
| 8/6 mm | R 1/8" | SC16C-08-18-P | 6900006 |
| 8/6 mm | R 1/4" | SC16C-08-14-P | 6900007 |
| 12/9 mm | R 1/4" | SC16C-12/9-14-P | 6900010 |
| 12/9 mm | R 3/8" | SC16C-12/9-38-P | 6900011 |
Grundversion
| Diametru | Filet exterior | Tip | Secvență |
|---|---|---|---|
| 6/4 mm | G 1/8" | SC36-06-18-P | 6910000 |
| 6/4 mm | G 1/4" | SC36-06-14-P | 6910001 |
| 8/6 mm | G 1/8" | SC36-08-18-P | 6910002 |
| 8/6 mm | G 1/4" | SC36-08-14-P | 6910003 |
