Ball valves - automatically operated

List prices MSP RO
BA010-10-0D
Ball valve with electrical actuator; 3-way-type; Sealing on three ports; Female thread; Body, Ball Brass; Seals PTFE/FKM; Medium temperature 0...+100°C; RP 1"; DN 25mm; Pressure range 0-16bar; Length 105mm; Operating time 8s; Voltage 12VAC/DC; Ball T
BA036-112-S0-01
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Single acting actuator; Control pressure 5,5...8bar; For steam Medium temperature -20...+198°C; RP 11/2"; Nominal diameter 40mm; Pressure range 0-15bar; Length 116mm; Actuator PAS0855-H; High temperature design
BA146-15-S0-01
STASTO Combination#br#Ball valve with pneumatic actuator; Butt weld ends Long; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 15mm; Pressure range 0-64bar; Length 265mm; Actuator PAS0525; Limit switch box EB0X03; 5/2-way solenoid valve - NAMUR type ABS54; 24VDC-LED
VB060-H-P0T
Electrical actuator; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 60Nm; Operating time 9s; Flange ISO5211 F05/F07-star 14mm; Voltage 100-240VAC; Protection class IP67; Feedback via potentiometer 0-5kOhm
BA696-10-L
High pressure ball valve; 3-way-type; Sealing on two sides; Pressure inlet just in front; Female thread; Body, Ball Stainless steel 1.4571; Seals POM/NBR; Medium temperature -30...+100°C; For liquids; G 1"; Nominal diameter 25mm; Pressure range 0...315bar; Length 113mm; Ball L; Hand lever
BADA-040-IITV-S0
Ball valve with pneumatic rotary actuator 85 single-acting, body and ball 1.4301, flange PN 16 connection DN40
FD0065NM00CWALTNL14SKA00XX
Pneumatic actuator; ATEX II 2G/D; Double acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 65mm; Flange ISO5211 F05/F07; Female square 14mm; Torque at 5,5bar 71Nm;
BA178-25-S2
Flanged ball valve with pneumatic actuator; Fire-safe; TA-Luft; Length According to ANSI B16.10; Flange ANSI150; Full bore; Body 1.4408; Ball 1.4401; Seals PTFE/Graphoil/FKM; Single acting actuator; Control pressure 4...8bar; Medium temperature -20...+160°C; Pressure range 0...20bar; Nominal diameter 25mm; Length 127mm; Actuator PAS0753
BA234-14-0L
Ball valve with electrical actuator; Female thread; Body, Ball 1.4571/1.4404; Seals POM/NBR; Medium temperature -30...+100°C; For liquids; G 1/4"; Nominal diameter 6mm; Pressure range 0...500bar; Length 69mm; Operating time 9s; Voltage 24VAC/DC
BA129-25-S0
Flanged ball valve with pneumatic actuator; Flange PN40; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0…40bar; Nominal diameter 25mm; Length 46mm; Actuator PAS0855; Free of oil and grease for oxygen
BAEB-025-SSTV-D0A
Ball valve with pneumatic rotary actuator 52 double-acting, body 1.4408, ball 1.4401, flange PN40 ATEX anti-static connection DN25
RI4746
Spring set; Suitable for Pneumatic actuator PAS200-4; Diameter 200mm
BA078-50-D0-02
Ball valve with pneumatic actuator; Butt weld ends; Body Steel; Ball 1.4301; Seals PTFE Graphite reinforced/FKM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+198°C; Compensation hole; Nominal diameter 50mm; Pressure range 0…15bar; Length 136mm; Actuator PAD100
BAC4-050-CICV-D0Z02
Ball valve with pneumatic actuator; Butt weld ends; Body Steel; Ball 1.4301; Seals PTFE Graphite reinforced/FKM; Double acting actuator; Control pressure 4,5...8bar; Medium temperature -10...+198°C; Compensation hole; Nominal diameter 50mm; Pressure range 0-25bar; Length 136mm; Actuator PAD100
BA119-10-D0
Ball valve with pneumatic actuator; 3-way-type; Sealing on three ports; Body, Ball 1.4401; Seals PTFE/EPDM-Perox; Double acting actuator; Full bore; Control pressure 5,5...8bar; Medium temperature -45...+140°C; Pressure range 0…40bar; G 1"; Nominal diameter 25mm; Length 102mm; Actuator PAD063; Ball T;
BA592-25-S0
ball valve with pneumatic actuator; flange PN40; housing AISI 316L polished; ball AISI 316L; seals PTFE/Kalrez; medium temperature -40...+160°C; single acting actuator; control pressure 5,5...8bar; medium temperature -40...+160°C; pressure range 0...40bar; nominal diameter 25mm; length 125mm; actuator PAS0855
BA340-25-S0-A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to EN558−1R27; Body, Ball 1.4408; Seals PTFE Thickness Reduced/Graphoil/FFKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 25mm; Pressure range 0-40bar; Flange PN40; Length 125mm; Actuator PAS0635; ATEX II 2G/D c T6
BA646-38S-S0
Ball valve with pneumatic actuator; 3-way-type; Sealing on two sides; Male thread According to ISO 8434-1 (DIN 2353); Body Zinc plated steel; Ball Steel; Seals POM/NBR; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+100°C; For liquids; Connection 38S/M52x2; Nominal diameter 25mm; Pressure range 0...315bar; Length 124mm; Ball T; Actuator PAS1255
BA791-32-S0-AH
Ball valve with pneumatic actuator; ATEX II 2 G/D T4; Butt weld ends; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+170°C; Connection 42,4 x 2mm; Nominal diameter 32mm; Pressure range 0-64bar; Length 112mm; Actuator PAS1005; Free of oil and grease for hydrogen
PAS0635-SS
Pneumatic actuator; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; ATEX II 2 G/D; Operating pressure range Max. 8bar; Completely made of stainless steel; Diameter 63mm; Flange ISO5211 F05/F07; Female square 14mm; Torque at 5,5bar 10,6Nm
