Flanged ball valve with pneumatic actuator BA043-32-S0-01

Name: Flanged ball valve with pneumatic actuator BA043-32-S0-01
Brand: STASTO
SKU: BA043-32-S0-01
Price: 3162.0 RON
Availability: InStock

Flanged ball valve with pneumatic actuator Series BADA; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 32mm; Length 54mm; Actuator PAS0855

Intrastat No.: 84818081
Country of origin: Italy
Weight: 7.91 Kg
Short Itemnumber: BA04332S001

flanged ball valve with pneumatic actuator series BADA; flange PN16; body steel; ball AISI 304; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...16bar; nominal diameter 32mm; length 54mm; actuator PAS0855

3.162,00 lei 3162.0 RON 3.162,00 lei

DN
- 32 mm
Length
- 54 mm
Pressure range
- 0...16 bar
Actuator
- PAS0855

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

dimension
DN	32 mm
Length	54 mm
pressure
Pressure range	0...16 bar
characteristics
Actuator	PAS0855

722000-32 x 1.0

Flanged ball valve 722000-32

Flanged ball valve Series 722000; Flange PN16, Full bore; Body Steel; Ball 1.4301; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -20...+160°C; Nominal diameter 32mm; Length 54mm

Add to Cart

PAS0755 x 1.0

Pneumatic actuator PAS0755

Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 75mm; Flange ISO5211 F05/F07; Female square 17mm; Torque at 5,5bar 17,5Nm

Add to Cart

RI3048 x 1.0
