WEI007

WEI007

STASTO Combination
fully assembled and tested
consists of
RE19-14-0,1/1
precision pressure regulator series RE19; relieving; inlet pressure max. 16bar; flow at 6bar/Δp=1bar 550Nl/min; without constant air consumption; accuracy app. 15mbar; connection 1/4"; pressure range 0,1-1,0bar; incl. suitable pressure gauge MA001-63R-1,6
Input and output C0P72M14B

Intrastat No.: 84811099
Country of origin: Germany
Weight: 0.84 Kg
Short Itemnumber: WEI007
https://www.stasto.ro/web/image/product.template/232717/image_1920?unique=7e94c24

STASTO Combination
fully assembled and tested
consists of
RE19-14-0,1/1
precision pressure regulator series RE19; relieving; inlet pressure max. 16bar; flow at 6bar/Δp=1bar 550Nl/min; without constant air consumption; accuracy app. 15mbar; connection 1/4"; pressure range 0,1-1,0bar; incl. suitable pressure gauge MA001-63R-1,6
Input and output C0P72M14B

701,80 lei 701.8 RON 701,80 lei

Not Available For Sale

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
Precision pressure regulator RE19-14-0,1/1
RE19-14-0,1/1 x 1.0
Precision pressure regulator RE19-14-0,1/1
Precision pressure regulator Series RE19; Relieving; Inlet pressure Max. 16bar; Flow at 6bar/Δp=1bar 550Nl/min; Without constant air consumption; Accuracy App. 15mbar; Connection 1/4"; Pressure range 0,1-1,0bar; Suitable manometer MA001-63R-1,6
Add to Cart
Bourdon tube manometer MA001-63R-1,6
MA001-63R-1,6 x 1.0
Bourdon tube manometer MA001-63R-1,6
Bourdon tube manometer Series MA001; Body Sheet steel; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Rear; Class 1,6; Diameter 63mm; Indicating range 0-1,6; Unit bar; Connection 1/4"
