SE01-D50-ST81-01
Pneumatically operated seat valve; NC; Body Stainless steel 1.4408; Seal PTFE; Welding ends DIN11850 Row 2; For gaseous media; Closing with flow; Medium temperature -30...+170°C; DN 50mm; Operating pressure 0...11bar; Control pressure 5...10bar; Diameter Actuator 80mm; Without dead space; Circlip/Piston springs Made of stainless steel; Head end gasket Klingersil Top-chem-2000; High temperature design up to 200°C; Mounting set For proximity switches M12x1
Country of origin: Germany
Weight: 100.0 Kg
Short Itemnumber: SE01D50ST8101
pneumatically operated seat valve; NC; body stainless steel AISI 316; seal PTFE; welding ends DIN11850 row 2; for gaseous media; closing with flow; medium temperature -30...+170°C; DN 50mm; operating pressure 0...11bar; control pressure 5...10bar; diameter actuator 80mm; without dead space; circlip/piston springs made of stainless steel; head end gasket Klingersil Top-chem-2000; high temperature design up to 200°C; mounting set for proximity switches M12x1
