REI001

REI001

STASTO Combination Fully assembled and tested; Inlet Swivel male elbow; Push-in 12mm; 1 Pieces Ball valve 1/2"; 1 Pieces 2/2-way solenoid valve Pilot-operated; NC; DN 12mm; Pressure DC 0,1-10bar; Incl. Coil 24VDC And Connector with LED and VDR; 1 Pieces Filter regulator; Relieving, Drain valve semi-automatic; Pressure range 0,5…8bar; Filter element 20ym; Flow at 6,3bar 2880Nl/min; Outlet Elbow adapter Female thread 1/2"; Flow direction From right to left

Intrastat No.: 84123100
Country of origin: Italy
Weight: 1.871 Kg
Short Itemnumber: REI001
https://www.stasto.ro/web/image/product.template/124412/image_1920?unique=351c77c

STASTO Combination fully assembled and tested; inlet swivel male elbow; push-in 12mm; 1 pieces ball valve 1/2"; 1 pieces 2/2-way solenoid valve pilot-operated; NC; DN 12mm; pressure DC 0,1-10bar; incl. coil 24VDC and connector with LED and VDR; 1 pieces filter regulator; relieving, drain valve semi-automatic; pressure range 0,5…8bar; filter element 20ym; flow at 6,3bar 2880Nl/min; outlet elbow adapter female thread 1/2"; flow direction from right to left

1.904,10 lei 1904.1 RON 1.904,10 lei

Not Available For Sale

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
Filter regulator FR-12-20-08-R-PE-SS
FR-12-20-08-R-PE-SS x 1.0
Filter regulator FR-12-20-08-R-PE-SS
Filter regulator Series FR01/FR; Relieving; Drain valve Semi-automatic; Pressure range 0,5...8bar; Filter element 20µm; Plastic bowl with protection cage; Connection 1/2"; Flow at 6,3bar/Δp=1bar 2880Nl/min; Max. inlet pressure 12,5bar
Add to Cart
2/2-way solenoid valve 21WA4K0B130
21WA4K0B130 x 1.0
2/2-way solenoid valve 21WA4K0B130
2/2-way solenoid valve Series 21W, 21WA; Pilot-operated; NC; Body Brass; Tube Stainless steel One-piece; Seal NBR; Medium temperature -10...+90°C; Standard coil BDA; Connector size 32mm; G 1/2"; DN 13mm; Pressure AC/DC 0,2-16bar; Length 66mm
Add to Cart
Y224VDC
Y224VDC x 1.0
Y224VDC
Solenoid coil Type Y2, ATEX- II 2G Ex mb IIC T4 / II 2D Ex mb tb IIIC T130°C; Cable length 3 m; Tension 24VDC-ATEX-Ex; Medium temperature max. 80°C
Add to Cart
Ball valve made of brass 3830-1/2"
3830-1/2" x 1.0
Ball valve made of brass 3830-1/2"
Ball valve made of brass Series 3830; Mini type; Female thread; Seals PTFE/NBR; Medium temperature -20...+90°C; Turning handle Polyamide; Pressure range 0...10bar; G 1/2"; Nominal diameter 10mm; Length 46mm
Add to Cart
