AutomationPackage - Pneumatics Store

RAU005

Name: RAU005
Brand: STASTO
SKU: RAU005
Price: 999999.0 RON
Availability: InStock

STASTO automation package silo 1 Redler

Weight: 7.12 Kg
Short Itemnumber: RAU005

999.999,00 lei 999999.0 RON 999.999,00 lei

Function
- -
Design
- -
Actuator
- -
Brand
- STASTO

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

Brand

STASTO

TH60-14-12-N x 1.0 Pcs

Female to male reducer adapter TH60-14-12-N

Female to male reducer adapter Series TH60; Nickel plated brass; Cylindrical thread; Female thread 1/4"; Male thread 1/2"

TH38C-14-B-Z x 1.0 Pcs

Detachable hex nipple TH38C-14-B-Z

Detachable hex nipple Series TH38C; Brass; Conical thread; Metal sealing; Thread 1/4"; Thread 1/4"

3831-1/4" x 1.0 Pcs

Ball valve made of brass 3831-1/4"

Ball valve made of brass Series 3831; Mini type; Female/male thread; Seals PTFE/NBR; Medium temperature -20...+90°C; Turning handle Polyamide; Pressure range 0...10bar; G 1/4"; Nominal diameter 8mm; Length 41mm

L-14-PE x 1.0 Pcs

Lubricator L-14-PE

Lubricator Series L; Plastic bowl with protection cage; Connection 1/4"; Flow at 6,3bar/Δp=1bar 1500Nl/min; Max. inlet pressure 16bar

PI12-10-14-N-0 x 1.0 Pcs

Straight male stud fitting PI12-10-14-N-0

Straight male stud fitting Series PI12; Nickel plated brass; Cylindrical thread; Diameter 10mm; Thread 1/4"

SCVE14 x 1.0 Pcs

Valve mounting set

Valve mounting set; For valves Series E5, 1/4"; For cylinder Series NWT; Minimum stroke 100mm;

E52W2S014 x 1.0 Pcs

5/2-way valve E52W2S014

5/2-way valve Series E5.; Pilot-operated; Pressure range 1,5...10bar; Actuation Electrical/electrical; Standard coil C001; Connector size 22mm; Connection 1/4"; Nominal diameter 8mm; Flow rate 1080Nl/min

SCN23050 x 2.0 Pcs

SCN23050

coil type SCN; connector size 32mm; voltage 230V/50-60Hz

PI16-10-14-N-0-360 x 1.0 Pcs

Swivel male elbow PI16-10-14-N-0-360

Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 10mm; Thread 1/4"

PI16-08-14-N-0-360 x 4.0 Pcs

Swivel male elbow PI16-08-14-N-0-360

Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/4"

SLS-M14-NS x 2.0 Pcs

Silencer SLS-M14-NS

Silencer Series SLS-NS; Operating pressure Max. 12bar; Connection 1/4"; Length 18mm; Body Messing vernickelt; Screen Edelstahl

NWT80-270 x 1.0 Pcs

NWT80-270

Profile magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Diameter 80mm; Stroke 270mm; Piston rod thread M20x1,5; Connection 3/8"; Push force at 6 bar 3014N
