PFE014

PFE014

STASTO Combination SET 3 Control valve
completely assembled, picked and checked
consists of
- 1 x 1820-1/2": ball valve made of brass; female thread; seal PTFE; medium temperature -20...+160°C; turning handle aluminum; connection G 1/2"; nominal diameter 15mm; pressure range 0-64bar; length 55mm
- 1 x SV01-12-11-10: safety valve; with twist lifting; body brass; compression spring stainless steel; application: compressed air, non-toxic and non-inflammable gases, which are allowed to flow freely; medium temperature -60…225°C; seal FKM; connection G 1/2"; DN 11mm; set pressure 10bar
- 1 x TH60-14-12-N: female to male reducer adapter; nickel plated brass; cylindrical thread; female thread 1/4"; male thread 1/2"
- 1 x TH29-12-N: T-adapter; nickel plated brass; cylindrical thread; female thread 1/2"
- 3 x TH38-12-N: hex nipple; nickel plated brass; cylindrical thread; thread 1/2"


Country of origin: Germany
Weight: 0.63 Kg
Short Itemnumber: PFE014
https://www.stasto.ro/web/image/product.template/220071/image_1920?unique=351c77c

STASTO Combination SET 3 Control valve
completely assembled, picked and checked
consists of
- 1 x 1820-1/2": ball valve made of brass; female thread; seal PTFE; medium temperature -20...+160°C; turning handle aluminum; connection G 1/2"; nominal diameter 15mm; pressure range 0-64bar; length 55mm
- 1 x SV01-12-11-10: safety valve; with twist lifting; body brass; compression spring stainless steel; application: compressed air, non-toxic and non-inflammable gases, which are allowed to flow freely; medium temperature -60…225°C; seal FKM; connection G 1/2"; DN 11mm; set pressure 10bar
- 1 x TH60-14-12-N: female to male reducer adapter; nickel plated brass; cylindrical thread; female thread 1/4"; male thread 1/2"
- 1 x TH29-12-N: T-adapter; nickel plated brass; cylindrical thread; female thread 1/2"
- 3 x TH38-12-N: hex nipple; nickel plated brass; cylindrical thread; thread 1/2"

573,20 lei 573.2 RON 573,20 lei

Not Available For Sale

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
Ball valve made of brass 1820-1/2"
1820-1/2" x 1.0
Ball valve made of brass 1820-1/2"
Ball valve made of brass Series 1820; Full bore; Female thread; Seal PTFE; Medium temperature -20...+160°C; Turning handle Aluminum; Connection G 1/2"; Nominal diameter 15mm; Pressure range 0-64bar; Length 55mm
Add to Cart
Safety valve FKM-1/2"-11-10
SV01-12-11-10 x 1.0
Safety valve FKM-1/2"-11-10
Safety valve Series SV01; With twist lifting; Body Brass; Compression spring Stainless steel; Application: Compressed air, Non-toxic and non-inflammable gases, which are allowed to flow freely; Medium temperature -60…225°C; Seal FKM; Connection G 1/2"; DN 11mm; Set pressure 10bar
