PFE012

PFE012

STASTO AutomationPackage/Combination SET 1 Cyclone
drawing CP255245
completely assembled, picked and checked
consists of
- 1 x 1820-1/2": ball valve made of brass; female thread; seal PTFE; medium temperature -20...+160°C; turning handle aluminum; connection G 1/2"; nominal diameter 15mm; pressure range 0-64bar; length 55mm
- 1 x SV01-12-11-10: safety valve; with twist lifting; body brass; compression spring stainless steel; application: compressed air, non-toxic and non-inflammable gases, which are allowed to flow freely; medium temperature -60…225°C; seal FKM; connection G 1/2"; DN 11mm; set pressure 10bar
- 1 x FR03-12-0,5/10; filter regulator; relieving; drain valve semi-automatic; inlet pressure max. 16bar; plastic bowl; filter element 5µm; connection 1/2"; flow at 6bar/Δp=1bar 3500Nl/min; pressure range 0,5-10bar
- 1 x TH60-38-12-N: female to male reducer adapter; nickel plated brass; cylindrical thread; female thread 3/8"; male thread 1/2"
- 3 x TH38-12-N: hex nipple; nickel plated brass; cylindrical thread; thread 1/2"
- 1 x TH38-12-N: hex nipple; nickel plated brass; cylindrical thread; thread 1/2"
- 1 x PI12-08-38-N-0: straight male stud fitting; nickel plated brass; cylindrical thread; diameter 8mm; thread 3/8"
- 1 x PI29-08-N: T-connector; nickel plated brass; diameter 8mm
- 14m PA-8/6-BU: plastic hose; material polyamide; multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; vacuum -0,87bar; temperature range -60...130°C; outside diameter 8mm; inside diameter 6mm; operating pressure at 23°C 20bar; colour blau


Weight: 1.93 Kg
Short Itemnumber: PFE012
https://www.stasto.ro/web/image/product.template/220064/image_1920?unique=90026b4

STASTO AutomationPackage/Combination SET 1 Cyclone
drawing CP255245
completely assembled, picked and checked
consists of
- 1 x 1820-1/2": ball valve made of brass; female thread; seal PTFE; medium temperature -20...+160°C; turning handle aluminum; connection G 1/2"; nominal diameter 15mm; pressure range 0-64bar; length 55mm
- 1 x SV01-12-11-10: safety valve; with twist lifting; body brass; compression spring stainless steel; application: compressed air, non-toxic and non-inflammable gases, which are allowed to flow freely; medium temperature -60…225°C; seal FKM; connection G 1/2"; DN 11mm; set pressure 10bar
- 1 x FR03-12-0,5/10; filter regulator; relieving; drain valve semi-automatic; inlet pressure max. 16bar; plastic bowl; filter element 5µm; connection 1/2"; flow at 6bar/Δp=1bar 3500Nl/min; pressure range 0,5-10bar
- 1 x TH60-38-12-N: female to male reducer adapter; nickel plated brass; cylindrical thread; female thread 3/8"; male thread 1/2"
- 3 x TH38-12-N: hex nipple; nickel plated brass; cylindrical thread; thread 1/2"
- 1 x TH38-12-N: hex nipple; nickel plated brass; cylindrical thread; thread 1/2"
- 1 x PI12-08-38-N-0: straight male stud fitting; nickel plated brass; cylindrical thread; diameter 8mm; thread 3/8"
- 1 x PI29-08-N: T-connector; nickel plated brass; diameter 8mm
- 14m PA-8/6-BU: plastic hose; material polyamide; multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; vacuum -0,87bar; temperature range -60...130°C; outside diameter 8mm; inside diameter 6mm; operating pressure at 23°C 20bar; colour blau

1.589,00 lei 1589.0 RON 1.589,00 lei

Not Available For Sale

  • Function
  • Design
  • Actuator
  • Brand

This combination does not exist.

Availability:
Contact Us

Share

Brand STASTO
Ball valve made of brass 1820-1/2"
1820-1/2" x 1.0 Pcs
Ball valve made of brass 1820-1/2"
Ball valve made of brass Series 1820; Full bore; Female thread; Seal PTFE; Medium temperature -20...+160°C; Turning handle Aluminum; Connection G 1/2"; Nominal diameter 15mm; Pressure range 0-64bar; Length 55mm
Safety valve FKM-1/2"-11-10
SV01-12-11-10 x 1.0 Pcs
Safety valve FKM-1/2"-11-10
Safety valve Series SV01; With twist lifting; Body Brass; Compression spring Stainless steel; Application: Compressed air, Non-toxic and non-inflammable gases, which are allowed to flow freely; Medium temperature -60…225°C; Seal FKM; Connection G 1/2"; DN 11mm; Set pressure 10bar
Filter regulator FR03-12-0,5/10
FR03-12-0,5/10 x 1.0 Pcs
Filter regulator FR03-12-0,5/10
Filter regulator Series Modul FR03; Relieving; Drain valve Semi-automatic; Inlet pressure Max. 16bar; Plastic bowl; Filter element 5µm; Connection 1/2"; Flow at 6bar/Δp=1bar 3500Nl/min; Pressure range 0,5-10bar
Hex nipple TH38-12-N
TH38-12-N x 4.0 Pcs
Hex nipple TH38-12-N
Hex nipple Series TH38; Nickel plated brass; Cylindrical thread; Thread 1/2"
T-connector PI29-08-N
PI29-08-N x 1.0 Pcs
T-connector PI29-08-N
T-connector Series PI29; Nickel plated brass; Diameter 8mm; Diameter 8mm
Plastic hose PA-8/6-BU-1
PA-8/6-BU-1 x 14.0 m
Plastic hose PA-8/6-BU-1
Plastic hose Series PA; Material Polyamide; Multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; Vacuum -0,87bar; Temperature range -60...130°C; Outside diameter 8mm; Inside diameter 6mm; Operating pressure at 23°C 20bar; Colour blau
