MES001
STASTO Combination
Fully assembled and tested
Consists of:
Control unit AX1073.000; 760x760x300mm
1 x Ball valve G1/4"
1 x Filter; G1/4"; Filter element 5ym
1 x Micro filter; G1/4"; Filter element 0,01ym
Rest content of oil 0,01 mg/m3
2 x Manometer; Diameter 63mm
Indicating range 0...10bar
1 x Precision pressure regulator; G1/4"
Without constant air consumption; Pressure range 0,1...1bar
1 x 3/2-way valve; G1/4"; 24VDC
1 x Check valve; G1/4"
1 x Pressure transmitter; Connection G1/4"
Measuring range 0...10bar; Outlet signal 4...20mA
1 x Pressure transmitter; Connection G1/4"
Measuring range 0...1bar; Outlet signal 4...20mA
2 x Flow monitors; Connection G1/4"
Air scale; Switching range 3...12Nl/min.
Contact NO contact
2 x 3/2-way valve; G1/8"; DN2,5mm
Pressure 0...6bar; Coil 24VDC
1 x Bulkhead fitting 10mm
4 x Bulkhead fitting 8mm
Electrical connections are on terminals
Inlet G1/4"
Intrastat No.: 84812090
Country of origin: Germany
Weight: 10.294 Kg
Short Itemnumber: MES001
Country of origin: Germany
Weight: 10.294 Kg
Short Itemnumber: MES001
STASTO Combination
fully assembled and tested
consists of:
control unit AX1073.000; 760x760x300mm
1 x ball valve G1/4"
1 x filter; G1/4"; filter element 5ym
1 x micro filter; G1/4"; filter element 0,01ym
rest content of oil 0,01 mg/m3
2 x manometer; diameter 63mm
indicating range 0...10bar
1 x precision pressure regulator; G1/4"
without constant air consumption; pressure range 0,1...1bar
1 x 3/2-way valve; G1/4"; 24VDC
1 x check valve; G1/4"
1 x pressure transmitter; connection G1/4"
measuring range 0...10bar; outlet signal 4...20mA
1 x pressure transmitter; connection G1/4"
measuring range 0...1bar; outlet signal 4...20mA
2 x flow monitors; connection G1/4"
air scale; switching range 3...12Nl/min.
Contact NO contact
2 x 3/2-way valve; G1/8"; DN2,5mm
pressure 0...6bar; coil 24VDC
1 x bulkhead fitting 10mm
4 x bulkhead fitting 8mm
electrical connections are on terminals
inlet G1/4"
No Specifications
1810-1/4"
x 1.0
Ball valve made of brass 1810-1/4"
Ball valve made of brass Series 1810, 1710; Full bore; Female thread; Seal PTFE; Medium temperature -20...+160°C; Hand lever Steel; Connection RP 1/4"; Nominal diameter 8mm; Pressure range 0-64bar; Length 51,5mm
MA001-63B-10
x 2.0
Bourdon tube manometer MA001-63B-10
Bourdon tube manometer Series MA001; Body Sheet steel; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Below; Class 1,6; Diameter 63mm; Indicating range 0-10; Unit bar; Connection 1/4"
FI03-14H
x 1.0
Filter FI03-14H
Filter Series Modul FI03; Drain valve Semi-automatic; Inlet pressure Max. 16bar; Plastic bowl; Filter element 5µm; Connection 1/4"; Flow at 6bar/Δp=1bar 2100Nl/min
FI03-14H-F0,01
x 1.0
Micro filter FI03-14H-F0,01
Micro filter Series Modul FI03-F0,01; Drain valve Semi-automatic; Inlet pressure 1,5...16bar; Plastic bowl; To separate liquids and solid particles; Rest content of oil 0,01mg/m3; Filter element 0,01µm; Connection 1/4"; Flow at 6bar/Δp=0,2bar 700Nl/min
MMB03-14H/38
x 1.0
MMB03-14H/38
Mounting bracket; Suitable to series Modul 03 MU3/MU2/FR/FI/LU-14H/38
K32W1S614
x 1.0
3/2-way valve K32W1S614
3/2-way valve Series K3.W; Pilot-operated; Pressure range 2,5...9bar; Actuation Electrical/spring; Type of coil CS; Connector size 16mm; Connection 1/4"; Nominal diameter 8mm; Function NC; Flow rate 1300Nl/min; Suitable silencer alle
C001-31-LVCV30-2
x 1.0
C001-31-LVCV30-2
Connector; Connector size 16mm; mit eingebauter LED, VDR und PVC-Kabel (3 m); Voltage 24VAC/DC
MV23-00-14
x 1.0
Check valve MV23-00-14
Check valve Series MV23; Axial type; Female thread; Nickel plated brass; Pressure range 0,2...10bar; Connection 1/4"; Flow rate 1500Nl/min; Length 42,5mm
PT02-14N-010-420
x 1.0
Pressure transmitter PT02-14N-010-420
Pressure transmitter Series PT02; Body, Wetted parts Stainless steel 1.4404; Pressure sensor Stainless steel AISI 316L; Seal NBR; Outlet signal 4...20 mA Proportional to applied pressure; Male thread 1/4"; Accuracy 1% of full pressure range; Measuring range 0...10bar
RE19-14-0,1/1
x 1.0
Precision pressure regulator RE19-14-0,1/1
Precision pressure regulator Series RE19; Relieving; Inlet pressure Max. 16bar; Flow at 6bar/Δp=1bar 550Nl/min; Without constant air consumption; Accuracy App. 15mbar; Connection 1/4"; Pressure range 0,1-1,0bar; Suitable manometer MA001-63R-1,6
MA001-63R-1,6
x 1.0
Bourdon tube manometer MA001-63R-1,6
Bourdon tube manometer Series MA001; Body Sheet steel; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Rear; Class 1,6; Diameter 63mm; Indicating range 0-1,6; Unit bar; Connection 1/4"
PT02-14N-001-420
x 1.0
Pressure transmitter PT02-14N-001-420
Pressure transmitter Series PT02; Body, Wetted parts Stainless steel 1.4404; Pressure sensor Stainless steel AISI 316L; Seal NBR; Outlet signal 4...20 mA Proportional to applied pressure; Male thread 1/4"; Accuracy 1% of full pressure range; Measuring range 0...1bar
RVM/U-L40012-MS
x 2.0
Flow monitors RVM/U-L40012-MS
Flow monitors Series RVM/U-L; Body Nickel plated brass; Float Brass; For any mounting position; Medium temperature Max. 120°C; Air scale; Switching range at 1 bar absolute; 20°C; NO contact; Connection 1/4"; Switching range 3...12Nl/min; Maximum pressure 300bar; U max. AC140/DC200V; I max. AC0,7/DC1A; Length 70mm
31A3AV25
x 2.0
3/2-way solenoid valve 31A3AV25
3/2-way solenoid valve Series 31A; Directly operated; NC; Body Brass; Tube Stainless steel One-piece; Seal FKM; Medium temperature -10...+120°C; Standard coil BDA; Connector size 32mm; G 1/8"; DN 2,5/2,5mm; Pressure AC/DC 0-6bar; Length 40mm
C003-31-CV20-6
x 2.0
C003-31-CV20-6
Connector; Connector size 32mm; With moulded PVC-cable (2 m); Voltage 0...250VAC/DC
PI27-08-N
x 4.0
Bulkhead fitting PI27-08-N
Bulkhead fitting Series PI27; Nickel plated brass; Diameter 8mm
PI27-10-N
x 1.0
Bulkhead fitting PI27-10-N
Bulkhead fitting Series PI27; Nickel plated brass; Diameter 10mm
TH24C-14-N
x 3.0
T-adapter Female thread/Female thread/Male thread TH24C-14-N
T-adapter Female thread/Female thread/Male thread Series TH24C; Nickel plated brass; Conical thread; Thread 1/4"
TH38C-14-N
x 2.0
Hex nipple TH38C-14-N
Hex nipple Series TH38C; Nickel plated brass; Conical thread; Thread 1/4"
TH28-14-18-B
x 1.0
Bulkhead TH28-14-18-B
Bulkhead Series TH28; Brass; Cylindrical thread; Thread 1 1/4"; Thread 2 1/8"
TH60-14-38-N
x 4.0
Female to male reducer adapter TH60-14-38-N
Female to male reducer adapter Series TH60; Nickel plated brass; Cylindrical thread; Female thread 1/4"; Male thread 3/8"
RA029-14
x 4.0
X-distributor RA029-14
X-distributor Series RA029; Material Aluminum; 4 Lateral outlets; Connection 1/4"
TH50-14-N-0
x 8.0
Plug screw TH50-14-N-0
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/4"
TH38C-18-14-N
x 2.0
Reduction hex nipple TH38C-18-14-N
Reduction hex nipple Series TH38C; Nickel plated brass; Conical thread; Thread 1/8"; Thread 1/4"
TH12-14-N-L43
x 2.0
Extension 1/4"
Extension Series TH12; Nickel plated brass; Cylindrical thread; Thread 1/4"
TH61C-14-N
x 2.0
Elbow adapter Male thread TH61C-14-N
Elbow adapter Male thread Series TH61; Nickel plated brass; Thread R 1/4"; Thread konisch
PI21-08-14-N-0-360
x 5.0
Male stud branch tee swivel PI21-08-14-N-0-360
Male stud branch tee swivel Series PI21-360; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/4"
PI16-08-14-N-0-360
x 6.0
Swivel male elbow PI16-08-14-N-0-360
Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/4"
PI12-08-14-N-0
x 4.0
Straight male stud fitting PI12-08-14-N-0
Straight male stud fitting Series PI12; Nickel-plated brass; Cylindrical thread; Diameter 8mm; Thread 1/4"
PI12-08-18-N-0
x 2.0
Straight male stud fitting PI12-08-18-N-0
Straight male stud fitting Series PI12; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/8"
PI16-10-14-N-0-360
x 1.0
Swivel male elbow PI16-10-14-N-0-360
Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 10mm; Thread 1/4"
SLS-M14-NS
x 1.0
Silencer SLS-M14-NS
Silencer Series SLS-NS; Operating pressure Max. 12bar; Connection 1/4"; Length 18mm; Body Messing vernickelt; Screen Edelstahl
