Glycerin manometer; Bourdon tube manometer; Body Stainless steel; Front ring Stainless steel Bright; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection 1/4" Rear; Class 1,6; Diameter 63mm; Indicating range -1...+5; Unit bar
Country of origin: Austria
Weight: 0.19 Kg
Short Itemnumber: MA03863RV5
glycerin manometer; bourdon tube manometer; body stainless steel; front ring stainless steel bright; measuring unit, motion work copper based alloy; front glass acryl; ambient temperature -20...+60°C; medium temperature max. +60°C; connection 1/4" rear; class 1,6; diameter 63mm; indicating range -1...+5; unit bar
Technical specifications
| Connection | 1/4" |
|---|---|
| Diameter | 63 mm |
| Indicating range | -1...+5 |
| Unit | bar |
| Connection | 1/4" |
| Diameter | 63 mm |
| Indicating range | -1...+5 |
| Unit | bar |
MA038-63R-V5
