Bourdon tube pressure gauge with Oil filling; Series MA030-B; Housing Stainless steel 1.4301; Measuring element 1.4404; Viewing window Instrument glass; Ambient temperature -20...+60°C; Medium temperature max. +180°C; Connection below; Diameter 63mm; Display area 0...10; Unit bar; Class 1,6; Connection G1/4"
Country of origin: Austria
Weight: 0.218 Kg
Short Itemnumber: MA03063B1003
Bourdon tube pressure gauge with Oil filling; Series MA030-B; Housing Stainless steel 1.4301; Measuring element 1.4404; Viewing window Instrument glass; Ambient temperature -20...+60°C; Medium temperature max. +180°C; Connection below; Diameter 63mm; Display area 0...10; Unit bar; Class 1,6; Connection G1/4"
Technical specifications
| Connection | 1/4" |
|---|---|
| Diameter | 63 mm |
| Indicating range | 0...10 |
| Unit | bar |
| Connection | 1/4" |
| Diameter | 63 mm |
| Indicating range | 0...10 |
| Unit | bar |
| Class | 1,6 |
MA030-63B-10-03
Documents
Czech / Čeština
Data Sheets
1-
PDF
Datový list · glycerinový manometr série MA030-B · CS
Data sheet 302 KB Updated 13/06/2026
German / Deutsch
Data Sheets
1-
PDF
Datenblatt · Glyzerinmanometer Serie MA030-B · DE
Data sheet 302 KB Updated 13/06/2026
English
Data Sheets
1-
PDF
Data sheet · Glycerin manometer Series MA030-B · EN
Data sheet 300 KB Updated 13/06/2026
Hungarian / Magyar
Data Sheets
1-
PDF
Adatlap · glicerines nyomásmérő óra sorozat MA030-B · HU
Data sheet 302 KB Updated 13/06/2026
Polish / Język polski
Data Sheets
1-
PDF
Arkusz danych · manometr glicerynowy Seria MA030-B · PL
Data sheet 302 KB Updated 13/06/2026
Slovenian / slovenščina
Data Sheets
1-
PDF
Podatkovni list · Glicerinski manometer serija MA030-B · SL
Data sheet 301 KB Updated 13/06/2026
Serbian (Latin) / srpski
Data Sheets
1-
PDF
Tehnički list · glicerinski manometar serije MA030-B · SRLATIN
Data sheet 301 KB Updated 13/06/2026
