LIP002

LIP002

STASTO automation package controller unit


Weight: 0.86 Kg
Short Itemnumber: LIP002
https://www.stasto.ro/web/image/product.template/101916/image_1920?unique=51880d1

733,90 lei 733.9 RON 733,90 lei

Not Available For Sale

  • Function
  • Design
  • Actuator
  • Brand

This combination does not exist.

Availability:
Contact Us

Share

Brand STASTO
Distributor DI03-12-4-14
DI03-12-4-14 x 1.0 Pcs
Distributor DI03-12-4-14
Distributor Series DI03; Material Anodized aluminum; Outlet thread 1/4"; Connecting thread 1/2"; Outlets Double-sided; Distance of outlets 36mm; Number of outlets 4
Relief valve RV01-14-3-6/12
RV01-14-3-6/12 x 1.0 Pcs
Relief valve RV01-14-3-6/12
Relief valve Series RV01; Body, Inner parts Brass; Seal FKM; Manual adjusting of discharge pressure (Lock nut); Medium temperature -20…+180°C; Without TÜV-inspection number; G 1/4"; Pressure range 6...12bar
Check valve MV23-00-14
MV23-00-14 x 1.0 Pcs
Check valve MV23-00-14
Check valve Series MV23; Axial type; Female thread; Nickel plated brass; Pressure range 0,2...10bar; Connection 1/4"; Flow rate 1500Nl/min; Length 42,5mm
RE02-14-0,5/8 x 1.0 Pcs
RE02-14-0,5/8
Pressure regulator; Relieving; Connection 1/4"; Flow at 6,3 bar 900Nl/min; Pressure range 0,5-8bar; Max. inlet pressure 16bar; Without manometer
Ball valve made of brass 3831-1/4"
3831-1/4" x 3.0 Pcs
Ball valve made of brass 3831-1/4"
Ball valve made of brass Series 3831; Mini type; Female/male thread; Seals PTFE/NBR; Medium temperature -20...+90°C; Turning handle Polyamide; Pressure range 0...10bar; G 1/4"; Nominal diameter 8mm; Length 41mm
Hex nipple TH38C-14-N
TH38C-14-N x 1.0 Pcs
Hex nipple TH38C-14-N
Hex nipple Series TH38C; Nickel plated brass; Conical thread; Thread 1/4"
Plug screw TH64C-18-N
TH64C-18-N x 1.0 Pcs
Plug screw TH64C-18-N
Plug screw Series TH64C; Nickel plated brass; Conical thread; Hexagon socket Without collar; Thread 1/8"
Bourdon tube manometer MA001-50R-10-D
MA001-50R-10-D x 1.0 Pcs
Bourdon tube manometer MA001-50R-10-D
Bourdon tube manometer Series MA001; Body Sheet steel; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Rear; Class 1,6; Diameter 50mm; Indicating range 0-10/0-145; Unit bar/psi; Connection 1/4"
