STASTO Combination
fully assembled and tested
consists of:
1x MMB03-34VH/10H mounting bracket;
1x FR03-10H-0.5/10-01
filter regulator series Modul FR03; relieving; drain valve semi-automatic; inlet pressure max. 16bar; plastic bowl; filter element 5µm; connection 1"; flow at 6bar/Δp=1bar 12000Nl/min; pressure range 0,5-10bar; Flow direction from right to left
2x 21H9KB180 2/2-way solenoid valve series SL200, 21H; pilot-operated; NC; body brass; seal NBR; medium temperature -10...+90°C; standard coil BDA; connector size 32mm; G 3/4"; DN 18mm; pressure AC 0,1...16bar; pressure DC 0,1...6bar; length 65mm
2x BDA08223DS
coil type BDA; standard; connector size 32mm; voltage 220-230V/50-60Hz
2x C003-32-6
connector; connector size 32mm; Standard; voltage 0...250VAC/DC
2x DI03-12-4-14
distributor; material anodized aluminum; outlet thread 1/4"; connecting thread 1/2"; outlets doppelseitig; distance of outlets 36mm; number of outlets 8
4 x Abgang 12mm Schlauch
4 x Abgang Verschlossen
STASTO Combination
fully assembled and tested
consists of:
1x MMB03-34VH/10H mounting bracket;
1x FR03-10H-0.5/10-01
filter regulator series Modul FR03; relieving; drain valve semi-automatic; inlet pressure max. 16bar; plastic bowl; filter element 5µm; connection 1"; flow at 6bar/Δp=1bar 12000Nl/min; pressure range 0,5-10bar; Flow direction from right to left
2x 21H9KB180 2/2-way solenoid valve series SL200, 21H; pilot-operated; NC; body brass; seal NBR; medium temperature -10...+90°C; standard coil BDA; connector size 32mm; G 3/4"; DN 18mm; pressure AC 0,1...16bar; pressure DC 0,1...6bar; length 65mm
2x BDA08223DS
coil type BDA; standard; connector size 32mm; voltage 220-230V/50-60Hz
2x C003-32-6
connector; connector size 32mm; Standard; voltage 0...250VAC/DC
2x DI03-12-4-14
distributor; material anodized aluminum; outlet thread 1/4"; connecting thread 1/2"; outlets doppelseitig; distance of outlets 36mm; number of outlets 8
4 x Abgang 12mm Schlauch
4 x Abgang Verschlossen
| Brand | STASTO |
|---|
