AutomationPackage - Pneumatics Store

HECH001

Name: HECH001
Brand: STASTO
SKU: HECH001
Price: 2441.4 RON
Availability: InStock

STASTO automation package 24 VDC

Weight: 2.47 Kg
Short Itemnumber: HECH001

2.441,40 lei 2441.4 RON 2.441,40 lei

Function
- -
Design
- -
Actuator
- -
Brand
- STASTO

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

Brand

STASTO

NSKU63-50-F-SEA x 1.0 Pcs

Compact magnetic cylinder NSKU63-50-F-SEA

Compact magnetic cylinder Series NSKU-F-SEA; Single acting; According to Unitop Standard; Pressure range 1...10bar; Piston rod with female thread; Diameter 63mm; Stroke 50mm; Piston rod thread M8; Connection 1/8"; Push force at 6 bar 1800N

SLN-M18-RB x 1.0 Pcs

Silencer SLN-M18-RB

Silencer Series SLN-RB; Sinterbronze; Thread Steel copper plated; Operating pressure Max. 16bar; Connection 1/8"; Length 23mm

PI16-08-18-N-0-360 x 1.0 Pcs

Swivel male elbow PI16-08-18-N-0-360

Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/8"

PI12-08-18-N-0 x 1.0 Pcs

Straight male stud fitting PI12-08-18-N-0

Straight male stud fitting Series PI12; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/8"

21HT3K0Y110 x 2.0 Pcs

2/2-way solenoid valve 21HT3K0Y110

2/2-way solenoid valve Series 21H..K0Y; Combined operated; NC; Body Brass; Stainless steel tube; Seal NBR; Medium temperature -10...+90°C; Connector size 32mm; G 3/8"; DN 11mm; Pressure AC 0-14bar; Pressure DC 0-5bar; Length 56mm; Standard coil BDA
