STASTO AutomationPackage

STASTO AutomationPackage
Completely picked and checked


Weight:
12.62 Kg
Short Itemnumber:
GAB003
https://www.stasto.ro/web/image/product.template/212907/image_1920?unique=69671bc

STASTO AutomationPackage
completely picked and checked

5.370,80 lei 5370.8 RON 5.370,80 lei

Not Available For Sale

excl. tax
  • Function
  • Design
  • Actuator
  • Brand

This combination does not exist.

Availability:
See availability

Technical specifications

Brand STASTO
Brand STASTO
BAC1-009-SSTV-S0 x 1.0 Pcs
Ball valve with pneumatic actuator BAC1-009-SSTV-S0
Ball valve with pneumatic actuator Series BAC1; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 2"; Nominal diameter 50mm; Pressure range 0-25bar; Length 136mm; Actuator PAS1005
SLN-M14-BB x 1.0 Pcs
Silencer SLN-M14-BB
Silencer Series SLN-BB; Sinterbronze; Thread Brass; Operating pressure Max. 16bar; Connection 1/4"; Length 32mm
E32W1S6M4-C001-03-C002-31-LV-2 x 1.0 Pcs
3/2-way valve E32W1S6M4-C001-03-C002-31-LV-2
E32W1S6M4 3/2-way valve Series E3.; Pilot-operated; Actuation Electrical/spring; Standard coil C001; Connector size 22mm; Connection 1/4"; Nominal diameter 8mm; Function NC; Pressure range 2,5-10bar; Flow rate 1080Nl/min C001-03 Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz C002-31-LV-2 Connector; Connector size 22mm; With integrated LED-yellow and VDR; Voltage 24VAC/DC
C0P72-F14-B x 1.0 Pcs
C0P72-F14-B
Coupling plug DN 7,2; Female thread; Brass; Pressure -0,87...35bar; Temperature Max. 100°C; Thread 1/4"
SLS-M14-NS x 2.0 Pcs
Silencer SLS-M14-NS
Silencer Series SLS-NS; Operating pressure Max. 12bar; Connection 1/4"; Length 18mm; Body Messing vernickelt; Screen Edelstahl
PV-16/10-NA-1 x 5.0 m
Fabric hose PV-16/10-NA-1
Fabric hose Series PV; Material PVC; Multiplier for operating pressure 60°C = 0,46; Temperature range -10...60°C; Colour Natural; Outside diameter 16mm; Inside diameter 10mm; Operating pressure at 23°C 14bar
C0C72-H10-B x 2.0 Pcs
Coupling DN 7,2 C0C72-H10-B
Coupling DN 7,2; Hose nozzle; Brass; Seal NBR; Pressure -0,87...35bar; Temperature Max. 100°C; Hose nozzle 10mm
158C x 2.0 Pcs
Hose clip 158C
Hose clip Series 158; Screw flight; Chromium steel 1.4016; Bandwidth 9mm; Clamping range 12-20mm
