Other materiales - Special armatures

List prices MSP RO
SG05-25-UWC80-01
Control valve Type SG05; DN25; PN10/40; NC; Material: Zinc plated steel, Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 6,4 (63%), Characteristic linear, Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA; With metal bellow
BS09-50-P-L
Ball sector valve; Wafer type; DN50; PN40; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring PEEK; Seals PTFE/O-ring Silicone PFA-Coated; KVS 109 (100%); Medium temperature -60...+220°C; Actuation Hand lever
SG06-65-UWC80-01
Control valve Type SG06; DN65; PN10/40; NC; Material: Steel 1.0619, Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 35 (63%), Characteristic linear, Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA
SG07-20-WWN1253-01
Control valve Type SG07, DN20; PN10/40; NC; Material: 1.4408; Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 6,4 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
3-MBFK25NC-544282
Module block Consists of: 3x2/2-way coaxial valve;Flange ANSI-RF 150lb; 0...16bar; 24VDC; DN25; NC; Directly operated; Body: Zinc plated steel; Medium: Hydrogen 80°C; Special seals; Back pressure tight; Incl. inspection certificate 3.1; Plunger PTFE-coated; Type plate Into English Made of stainless steel; ATEX CE Ex nA II T3 And CE Ex tc IIIC T195°C;; Special version
3-MBFK25NC-546741
Module block Consists of: 3x2/2-way coaxial valve;Flange ANSI-RF 150lb; 0...16bar; 24VDC; DN25; NC; Directly operated; Body: Zinc plated steel; Medium: Hydrogen 80°C; Special seals; Back pressure tight; Incl. inspection certificate 3.1; PTFE-coated armature; Type plate Into English Made of stainless steel; ATEX CE Ex nA II T3 And CE Ex tc IIIC T195°C;; Special version
BS09-50-P-D0
Ball sector valve Pneumatically double acting; Wafer type; DN50; PN40; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring PEEK; Seals PTFE/O-ring Silicone PFA-Coated; KVS 70 (100%); Medium temperature -60...+220°C; Actuator PAD063-H
BS01-40-V-D0-01
Ball sector valve; Wafer type; DN40; PN40; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring Stellite; Seals made of FKM; KVS 64 (100%); Characteristic equal percentage Medium temperature -15...+200°C; Incl. Pneumatic actuator Double acting PAD075
SG07-40-UWC1253-03
Control valve Type SG07, DN40; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 11 (40%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
SG07-40-UWC1253-06
Control valve Type SG07, DN40; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 16 (63%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
SG07-40-UWF1253-01
Control valve Type SG07, DN40; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Stainless steel/SFC; Kvs-value 11 (100%); Characteristic Equal percentage; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA; Position feedback 4-20 mA
SG06-50-UWC80-03
Control valve Type SG06; DN50; PN10/40; NC; Material: Steel/1.0619; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 28 (63%), Characteristic linear, Actuator diameter 80mm; Digital positioner 8049; 4-wire; 4-20mA; ATEX Zone 22; Feedback module with 2 integrated limit indicators RM5
SG05-40-UWC80-01
Control valve Type SG05; DN40; PN10/40; NC; Material: Zinc plated steel, Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 26 (100%), Characteristic linear, Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA; ATEX zone 1; Silicone-free; Ink. Earthing connection
8044-GS1-040-4062584
040VE0101M--91--ZC GS control valve, DN40, PN10/40, NC housing 1.4571, sliding pairing STN2, KV26(100%) LIN. incl. digital positioner, input 4-20mA/2-10V
CVFV-50-NC-004
2/2-way coaxial valve; Externally controlled; Flange DN50 PN40; 0...40bar; 24VDC; NC; Body: Stainless steel; Medium: Oil; Incl. 5/2-way pilot valve; Incl. LED; Special version
CVF-15-N0-016
2/2-way coaxial valve; Directly operated; Flange DN15; PN100; 0...63bar; 220VDC; NO; Body: Stainless steel; Medium: Natural gas 210°C; Special seals; Incl. 3 inductive limit switches (B.HT); 1 x For open position; 2 x For closed-position; 4 x Preparation for limit switch; Incl. inspection certificate 3.1; Incl. Mounting bracket; Incl. material certificate; ATEX CE Ex II 3G Ex ec IIC T3 Ta -20...+80°C Gc / CE Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc And Ex II 3G Ex h IIC T3 Gc / Ex II 3D Ex h IIIC T195°C Dc; Z-IS-TAF-MUC-16-06-2652116-008-Rev.01; HT-Special version
SG17-32-WWF0,3/1,2
Gleitschieber-Druckregler; eigenmediengesteuert; Nenndruck PN10/40; Zwischenflanschausführung; Material Edelstahl 1.4408/1.4581; Membrane; Dichtscheibe feststehend Edelstahl 1.4571 beschichtet; Dichtscheibe beweglich SFC; Nennweite 32mm; Kvs-Wert 16 (100%); Kennlinie linear; Druckbereich 0,3...1,2bar; Einbaulänge 33mm
5MB-VMK20NC-542442
5-fold-Module block Consists of 5 Pieces VMK20NC-71361; Incl. end plate; Module block Anodized; Special version
8021-GS1-032-4071594
032VG0003M-----1ZC GS1 control valve, DN32, PN10/40, NC body carbon steel, sliding pair standard KVS8 (100%), characteristic equal percentage, incl. digital positioner, 8049-4 wire
SG07-15-WWF1253-02
Control valve Type SG07, DN15; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc SFC; Kvs-value 0,44 (10%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
