Special armatures

Control valve Type SG07, DN100; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 154 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA

SG07-100-WWC1253-02

Control valve Type SG07, DN100; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 62 (40%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA

CVTEH-40-NC-002

2/2-way coaxial valve; Externally controlled; G11/2"; 0...200bar; DN40; NC; Body: Stainless steel; Medium: Demineralized water 80°C; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED (B.); ATEX Ex II 2G Ex h IIC -20...+80°C Gb X / Ex II 2D h IIIC -20...+80°C Db X; Incl. inspection certificate 3.1; Hydraulically controlled 15...30bar; Special version

SG13-100-UWFEC5-01

Control valve Type SG13, DN100; PN10/40; Material: Carbon steel; Fixed disc 1.4571 Coated; Sliding disc 1.4571/SFC; Kvs-value 77 (100%); Characteristic equal percentage; Control actuator 2,0 kN; 100-240V50/60Hz; Position electronics 4-20mA, 2-10V; Feedback 4-20mA, 2-10V; 2 Limit switch

SG14-25-WWN12503-02

Sliding gate valve with diaphragm-actuator Type SG14; DN25; PN100; Body: Stainless steel AISI 316Ti, Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 11 (100%); Characteristic linear; Diaphragm actuator 250cm²; Incl. I/P-positioner Samson 3730-2Ex; IP65; Safety position; Spring opened

8030-GS1-080-4048397

080VM01-1M--91--Z2 GS motorised control valve,type 8030, DN80, PN10/40 body stainless steel, sliding pair STN2 KVS92 (100%), characteristic linear, 230VAC, 2.0kN, IP67 incl. 2 travel-dependent limit switches

CVFV-150-NC-001

2/2-way coaxial valve; Externally controlled; Flange PN40 DN150; 0...40bar; NC; Body: Steel nickel plated; Medium: Hot air +160°C; Control port G3/8"; Special seals; Special version

SG10-150-UWN2504-02

Control valve Type SG10; DN150; PN10/40; NC; Material: Zinc plated steel; Fixed disc STN2/STN3; Sliding disc STN2/STN3; Kvs-value 338 (100%); Characteristic Linear; Diaphragm actuator 250cm²; Incl. Coupler For positioner Eckardt, ABB-TZID/TZID-C, Siemens-PS2, Samson-3730/DVC2000; Special version

CVF-65-N0-002

2/2-way coaxial valve; Directly operated; Flange DN65 PN16; 0...16bar; 230VAC; NO; Body: Stainless steel; Medium: Mineral oil ISO VG46; Special seals; ATEX Ex II 3G Ex nA IIC T3 Ta -20...+80°C Gc / Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc IP65 And CE Ex II 3 GD c T4 ; Special version

SG09-125-UWF2504-01

Control valve Type SG09, DN125; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Stainless steel/SFC; Kvs-value 237 (100%); Characteristic Linear; Diaphragm actuator 250cm²; Positioner Type 8047, 0/4-20mA

SG12-100-UWFEC5-01

Sliding gate valve with electrical actuator Type SG12; DN100; PN10/40; Body: Zinc plated steel, Fixed disc Stainless steel AISI 316Ti Coated; Sliding disc SFC; Kvs-value 95 (63%); Characteristic linear; additional metal bellows; 100-240VAC; Input signal 4-20mA; Outlet signal 4-20m; Operating time 13,1s

3-VD-5-PCDH10NC-552480

Module block Consists of: 3x2/2-way high pressure valve; G1/2"; 0...500bar; 24VDC; DN10; NC; Directly operated; Body: Brass; Medium: Emulsion/Oil; Incl. 5/2-way pilot valve; Incl. LED;Incl. mounting holes; Special version

SG17-125-WWC1/2,5

Sliding gate-pressure regulator; Controlled by own medium; Nominal pressure PN10/40; Wafer type; Material Stainless steel 1.4408; Diaphragm CR; Fixed disc Stainless steel AISI 316Ti coated; Sliding disc Carbon material; Nominal diameter 125mm; Kvs-value 237 (100%); Characteristic Linear; Pressure range 1...2,5bar; Length 52mm

SG09-50-WWN5006-01

Control valve Type SG09, DN50; PN100; NC; Material: 1.4408; Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 12 (63%); Characteristic Equal percentage; Diaphragm actuator 500 cm²; Digital positioner; 4-wire; 4-20mA

SG07-150-UWF2503-02

Control valve Type SG07; DN150; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc SFC; Kvs-value 338 (100%); Characteristic Linear; Diaphragm actuator 250cm²; P/P-positioner 0.2-1bar

SG19-100-WWC125-01

Control valve Type SG19, DN100; ANSI150; NC; Material: 1.4571/1.4581; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 77 (100%); Characteristic Equal percentage; Piston actuator 125mm; Digital positioner; 4-wire; 4-20mA

CVF-65-NC-009

2/2-way coaxial valve; Directly operated; PN16; 0...16bar; 230VAC; DN65; NC; Body: Stainless steel; Medium: Demineralized water; Incl. LED; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Special version

SG07-100-WWC250-01

Control valve Type SG07; DN100; ANSI150; NC; Material: 1.4408, Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 154 (100%), Characteristic linear, Actuator diameter 250mm; Digital positioner; 4-wire; 4-20mA; Pressure range 0-9bar

CVFE-40-NC-003

2/2-way coaxial valve; Externally controlled; Flange DN40; ANSI-RF 1500 lb; 0...100bar; NC; Body: Stainless steel; Medium: Fuel 60°C; Special seals; Inspection certificate 3.1; Mounting bracket; Incl. material certificate; SIL3; CE0036-Mark; ATEX Ex II 2G Ex h IIC T-20°C...+70°C Gb; Ex II 2D Ex h IIIC T-20°C...+70°C Db; Incl. 2 inductive limit switches GO-Switch; Special version

15205

Connecting cable With Union elbow; M12; Cable length 5m; 3-pin; Coating PUR Black; 2 LED
