Special armatures

CVF-80-NC-004

2/2-way coaxial valve; ANSI-RF 150lb; 0…16bar; 125VDC; DN80; NC; Directly operated; Body: Zinc plated steel; Medium: Heating oil 60°C; Incl. test report 2.2; Special version

015VG0103M--912-ZC0 GS control valve, DN 015, PN10/40, NC body stainless steel, sliding pair STN2 KVS= 0,71(16%), linear, incl. digital positioner 8049-4 wire, 0/4-20mA and 2 inductive limit switches (10-30 VDC)

SG06-80-UWC80-02

Sliding gate valve with piston actuator Type SG06; DN80; PN10/40; NC; Material: Zinc plated steel, Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 92 (100%), Characteristic linear, Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA

CV6T-10-NC-001

6-fold-Module block Consists of:
2/2-way coaxial valve; G1/4"; 0...100bar; 24VDC; DN8; NC; Directly operated; Body: Brass; Medium: Water; Incl. LED; Special version

SG06-50-WWC80-03

Control valve Type SG06; DN50; PN10/40; NC; Material: 1.4408 Respectively 1.4408/1.4401, Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 10 (20%), Characteristic linear, Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA

SG06-65-WWC80-02

Control valve Type SG06; DN65; PN10/40; NO; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 35 (63%), Characteristic linear; Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA

8044-GS1-100-4065441

100VE0002M------ZC-S7 GS1 control valve, 8044, wafer type, NC DN100, PN10/40, body steel, sliding pair standard KVS value 154 (100%), linear, incl. digital positioner 8049, 4-wire, 24VDC, control signal 0-10V

BS10-80-D-S0-01

Ball sector valve; Wafer type; DN80; PN25; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring PTFE; Seals PTFE/O-ring EPDM; KVS 255 (100%); Medium temperature -40...+140°C; Incl. Pneumatic actuator Single acting; Incl. TCR-Module; 2 Micro switches; Visual indication

CVF-50-NC-012

2/2-way coaxial valve; Flange DN50 PN16; 0...16bar; 24VDC; NC; Directly operated; Body: Stainless steel; Medium: Jet Fuel 60°C; Special seals; ATEX II 3G Ex nA IIC T3 Ta -20…+80°C Gc / CE Ex tc IIIC T195°C And II 3D Ex tc IIIC T195°C Ta -20…+80°C Dc IP65; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Incl. inspection certificate 3.1; Special version

CVFV-P-80-NC-002

2/2-way coaxial valve; DN80, PN40; 0...40bar; 24VDC; NC; Externally controlled; Body: Steel nickel plated; Medium: Nitrogen/Helium; Incl. 5/2-way pilot valve Festo; Incl. 2 inductive limit switches OPEN/CLOSED; Incl. inspection certificate 3.1; CE-label; Special version

FK80NC-519787

2/2-way coaxial valve, DN80, PN16 0-16 bar, 24VDC, NC, direct-acting Body: nickel-plated steel, Medium: natural gas incl. cube connector, special seals, CE marking, inspection certificate 3.1 and 2 inductive limit switches

SG07-80-UWC1253-05

Control valve Type SG07, DN80; PN10/40; NC; Material: Carbon steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 92 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA; Feedback module with 2 integrated limit indicators

SG07-100-UWC1253-05

Control valve Type SG07, DN100; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 154 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA

CVFE-40-NC-005

2/2-way coaxial valve; Externally controlled; Flange DN40; ANSI-RF 1500 lb; 0...100bar; NC; Body: Stainless steel; Medium: Fuel 70°C; Special seals; Incl. test report 2.2; CE0036-Mark; ATEX Ex II 2G Ex h IIC T-20°C...+70°C Gb And Ex II 2D Ex h IIIC T-20°C...+70°C Db; Special valve testing; Prepared for 1 limit switch; Special version

CVTE-P-50-NC-003

2/2-way coaxial valve; Externally controlled; G2"; 0...100bar; 24VDC, DN50; NC; Body: Stainless steel; Medium: Hydrogen; Special seals; Incl. 5/2-way pilot valve; ATEX-design CE Ex II GD c T4; Incl. 2 inductive NAMUR limit switches OPEN/CLOSED (B.); Special version

FK50NC-543129

2/2-way coaxial valve; PN16; 0...16bar; 220VDC; DN50; NC; Directly operated; Body: Stainless steel; Medium: CO2/H2/Air; With manual emergency override; Incl. 1 inductive limit switch; ATEX; Special version

CVFE-P-50-NC-007

2/2-way coaxial valve; Externally controlled; NC; Stainless steel; DN 50mm; Flange ANSI300; Pressure range 0...63bar; Medium Natural gas; Incl. 5/2-way pilot valve 24VDC; Mounting bracket; Connecting cable 10m; Special control connection; Special seals; Mark CE0036; ATEX Ex II 2G Ex h IIC T-20°C...+70°C Gb X; Ex II 2D Ex h IIIC T-20°C...+70°C Db X; Special version

BS08-80-T-D0-01

Ball sector valve; Wafer type; DN80; PN25; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring Stellite; Seals made of FKM; KVS 300 (100%); Characteristic equal percentage Medium temperature -15...+200°C; Incl. Pneumatic actuator Double acting PAD100; Control pressure 5,5...8bar

CVFV-80-NC-005

2/2-way coaxial valve;externally controlled; ANSI300; 0...40bar; DN80; NC; externally controlled; body: zinc plated steel; medium: nitrogen/vacuum; vacuum-test with certificate; incl. 2 inductive limit switches (I.); incl. inspection certificate 3.1; special version
