Special armatures

List prices MSP RO
SG07-65-UWC1253-01
Control valve Type SG07, DN65; PN10/40; NC; Material: 1.0570/1.0619; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 52 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
CVF-80-NC-011
2/2-way coaxial valve; Directly operated; Flange DN80 PN16; 0…16bar; 230VAC; NC; Body: Zinc plated steel; Medium: Diesel; Special seals; Incl. inspection certificate 3.1; Special version
CVF-40-N0-011
2/2-way coaxial valve; Flange DN40 PN40; 0...40bar; 230VAC; NO; Directly operated; Body: Stainless steel; Medium: ISO VG46 80°C; Special seals; Back pressure tight Up to 16bar; Cable gland M20x1,5; ATEX CE Ex nA II T3, CE Ex tc IIIC T195°C And CE Ex II 3 GD c T4; Incl. 2 inductive NAMUR limit switches OPEN/CLOSED (I.); With manual operation; Incl. inspection certificate 3.1; Special version
8030-GS1-065-4048892
065VM00-4M------Z-1 GS-Motorstellventil,Typ 8030, DN65, PN10/40 Gehäuse C-Stahl 1.0570, Gleitpaarung Standard KVS52 (100%), Kennlinie liniear, 230VAC, 0,9kN, IP65 Rückmeldung über Potentiometer 1000 Ohm
4047158
Function unit; SG-Valve; DN125; Kvs-value 237 (100%); Characteristic Linear; STN2; Form A
SG06-50-WWC80-05
Control valve Type SG06; DN50; PN10/40; NC; Material: 1.4408 Respectively 1.4408/1.4401; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 28 (63%); Characteristic linear; Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA
SG07-32-WWC1253-03
Control valve Type SG07, DN32; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 10 (63%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 2-wire; 4-20mA; IP65
CVF-40-NC-038
2/2-way coaxial valve; Directly operated; Flange DN40; PN40; 0...40bar; 220VDC; NC; Body: Stainless steel; Medium: Hydrogen Gaseous +80°C; Special seals; Terminal box; Back pressure tight max. 16bar; Manual emergency override; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Vacuum-test with certificate; Incl. inspection certificate 3.1; Material certificate; ATEX CE Ex II 3G Ex ec IIC T3 Ta -20...+80°C Gc; CE Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc; Ex II 3G Ex h IIC T3 Gc; Ex II 3D Ex h IIIC T195°C Dc; Special version
VSV-F-125NC-501150
2/2-way-coaxial valves; Externally controlled; NC; Body: Aluminum; Medium: Emulsion; DN 125mm; Flange PN16; Pressure range 0-16 bar; Hydraulically controlled 30-60 bar; Special version
8030-GS1-025-4072678
025VM00-4M-----1Z--S--M GS motor valve type: 8030 wafer DN25, PN 10/40, body: carbon steel 1.0570 motor force 0.9KN, IP65, 230VAC, with overrun controller 0-20mA differential pressure: 6bar, characteristic equal percentage Kvs 5 (100%), disc pair carbon / stainless steel
SG07-65-UWC1253-04
Control valve Type SG07, DN65; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 35 (63%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
8020-GS1-040-4065387
040VP0003M-----1Z61 GS control valve,8020,wafer,NC DN40,PN10/40, housing steel, sliding pairing standard Kvs value 11(100%), equal-percentage, with mounted positioner without pressure gauge, type SRI 986,EEx ib IIC, IP 54, incl. 2 limit signal transmitters inductive for i/p positioner Ex protected (Eckardt) replaces type 040VP0003M-----1Z6B
CVFEH-15-NC-001
2/2-way coaxial valve; Externally controlled; Flange DN15; ANSI-RF 1500 lb; 0...200bar; NC; Body: Stainless steel; Medium: Fuel 60°C; Special seals; Preparation for limit switch; Inspection certificate 3.1; Mounting bracket; Incl. material certificate; SIL3; ATEX Ex II 2G Ex h IIC T-20°C...+70°C Gb; Ex II 2D Ex h IIIC T-20°C...+70°C Db; Special version
CVFEH-15-NC-003
2/2-way coaxial valve; Externally controlled; Flange DN15; ANSI-RF 1500 lb; 0...200bar; NC; Body: Stainless steel; Medium: Fuel 60°C; Special seals; Preparation for limit switch; Inspection certificate 3.1; Mounting bracket; Incl. material certificate; SIL3; ATEX Ex II 2G Ex h IIC T-20°C...+70°C Gb; Ex II 2D Ex h IIIC T-20°C...+70°C Db; Special version
SG09-25-WWN1253-01
Control valve Type SG09, DN25; PN10/40; NC; Body: Stainless steel; Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 2,4 (40%); Characteristic Equal percentage; Diaphragm actuator 125cm²; Digital positioner; 4-wire; Control signal 4-20mA; Position indicator; Stainless steel-Type plate
5-VSVF80NC-520546
2/2-way coaxial valve, DN80, PN40 0-40 bar, 230VAC, NC, pilot-operated Body: zinc-plated steel, Medium: mineral oil ISO VG 100 incl. 5/2-way pilot valve, LED and CE0589 marking
CVFV-80-NC-006
2/2-way coaxial valve; Externally controlled; Flange PN40 DN80; 0...40bar; NC; Body: Steel nickel plated; Medium: Hot air +160°C; Control port G3/8"; Special drive; Special seals; Special version
SG17-65-WWC2/5-01
Sliding gate-pressure regulator; Controlled by own medium; Nominal pressure PN10/40; Wafer type; Material Stainless steel 1.4408; Diaphragm CR; Fixed disc Stainless steel AISI 316Ti coated; Sliding disc Carbon material; Nominal diameter 65mm; Kvs-value 52 (100%); Characteristic Linear; Pressure range 2...5bar; Length 46mm
SG17-65-WWC4/10
Sliding gate-pressure regulator; Controlled by own medium; Nominal pressure PN10/40; Wafer type; Material Stainless steel 1.4408; Diaphragm CR; Fixed disc Stainless steel AISI 316Ti coated; Sliding disc Carbon material; Nominal diameter 65mm; Kvs-value 52 (100%); Characteristic Linear; Pressure range 4...10bar; Length 46mm
SG10-32-WWF1253-02
Control valve Type SG10; DN32; PN10/40; NC; Material: 1.4571/1.4581; Fixed disc 1.4571 Coated; Sliding disc SFC; Kvs-value 16 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Mounted I/P-positioner For single acting linear actuators; Sipart PS2; Input signal 4-20mA; II2G Ex ia IIC T6/4 Gb; Area 1
