Special armatures

List prices MSP RO
BS07-50-V-CE-01
Ball sector valve KS2; Wafer type; DN50; PN40; Body 1.4408/1.4404; Ball sector Stainless steel Polished; Seat ring PTFE; Seals made of FKM; Medium temperature -15…+170°C; With Electric control actuator PSQ; Voltage 24VAC/DC; Protection class IP67; Visual position indicator; And Manual emergency override; Incl. Position feedback 0/4-20mA Respectively 0/2-10V; Additional 2 limit switches
SG10-25-WWF1252-02
Control valve Type SG10; DN25; PN10/40; NC; Material: 1.4571/1.4581; Fixed disc 1.4571 Coated; Sliding disc SFC; additional metal bellows 1.4571; Kvs-value 11 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Incl. Coupler For positioner SIPART PS2
CVTEH-P-15-N0-005
2/2-way coaxial valve; G1/2"; 0…200bar; DN15; NO; Externally controlled; Body: Stainless steel; Medium: Demineralized water 45°C; Incl. 5/2-way pilot valve 24VDC; Incl. LED; ATEX CE Ex II 3 GD c T4; Incl. 2 inductive limit switches (B.); Special version
8044-GS1-025-4064289
025VE0001M------ZC GS1 control valve, DN25, PN10-40, NC body carbon steel, sliding pair standard, actuator D80 KVS= 11 (100%), linear, incl. digital positioner 8049-4 wire, 0/4-20mA
SG08-25-WWNECB-01
Control valve with electrical actuator Type SG08; DN25; PN10/40; Body: Stainless steel AISI 316, Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 11 (100%); Characteristic linear; Safety position NC; Voltage 90-260VAC; Control actuator CA260C; Setpoint value input 4-20mA; Position feedback 4-20 mA; 2 Limit switch; Operating time 12,5s
SG33-15-UWF80-01
control valve type SG33, DN15; PN10/40; NC; material: zinc plated steel; fixed disc AISI 316Ti coated; sliding disc SFC; kvs-value 0,71 (16%); characteristic linear; Membrane drive 80cm²; digital positioner; 4-wire; 4-20mA; short execution
SG11-80-UWC80-0,5/6
Sliding gate-pressure regulator Type SG11, Short design; DN80; PN10/40; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 80 (100%); Characteristic Linear; Piston actuator 80cm²; Pressure range 0,5...6Bar; Remotely controlled
8040-GS1-080-4041008
080VB0001M------M6 GS shut-off valve type 8040 DN80 wafer body PN10-40, body C-steel 1.0570 chrome-plated, fixed sealing disc stainless steel 1.4571 coated, moving disc carbon material with metallic impregnation
CVTE-40-NC-001
2/2-way coaxial valve; Externally controlled; G11/2"; 0...63bar; DN40; NC; Body: Stainless steel; Medium: Demineralized water; Special seals; Special version
8044-GS1-020-4067208
020VE0001M----2-ZC GS1 control valve, DN20, PN10-40, NC body carbon steel, sliding pair standard, actuator D80 KVS= 1 (16%), linear, incl. digital positioner 8049-4 wire, 0/4-20mA
SG06-15-UWC80-01
Control valve Type SG06, DN15; PN10/40; NC; Material: 1.0570; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 0,14 (2,5%); Characteristic Linear; Actuator diameter 80mm; Digital positioner; 4-wire; ATEX Zone 22 (Dust D, II Category 3)
CVT-32-NC-011
2/2-way coaxial valve; Directly operated; 11/4" NPT; 0...63bar; 24VDC; DN32; NC; Body: Stainless steel; Medium: Hydrogen peroxide; Incl. LED; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Incl. inspection certificate 3.1; ; Special version
FK32NC-528631
2/2-way coaxial valve, DN32, PN16 0-16 bar, 230VAC, NC, direct-acting Housing: stainless steel, Medium: air containing salt water incl. LED, special seals and 2 inductive limit switches
FK40NC-518352
2/2-way coaxial valve, DN40, PN40 0-40 bar, 24VDC, NC, direct-acting Body: stainless steel, Medium: demineralised water special seals, incl. LED, incl. inspection certificate 3.1
CV4TE-P-15-NC-001
4-fold-Module block; 2/2-way coaxial valve; G1"; 0…63bar; 24VDC; Coil M12x1; DN15; NC; Externally controlled; Body: Brass; Medium: Emulsion; Incl. 5/2-way pilot valve; Special thread; With additional thread In End plate; Special version
SG07-65-UWC1253-02
Control valve Type SG07, DN65; PN10/40; NC; Material: 1.0570/1.0619; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 52 (100%); Characteristic Linear; Diaphragm actuator 125cm²; P/P positioner; 0,2-1bar
SG06-25-WWC80-04
Control valve Type SG06, DN25; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 11 (100%); Characteristic Linear; Actuator diameter 80mm; I/P-positioner 8047
SG08-65-UWF-E01-01
Control valve Type SG08, DN65; PN10/40; CA-24VAC/DC; Material: Carbon steel; Fixed disc 1.4571 Coated; Sliding disc 1.4571/SFC; Kvs-value 52(100%); Characteristic Linear; Operating pressure 0...17bar; Operating time 132s
SG06-15-WWC80-08
Control valve Type SG06, DN15; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 4 (100%); Characteristic Linear; Actuator diameter 80mm; Digital positioner; 4-wire
CVCDH-P-15-NC-004
Coax-2/2-way-lateral valve; Externally controlled; G3/4"; 0...500bar; 24VDC; DN15; NC; Body: Stainless steel; Medium: Hydrogen Gaseous; Incl. 5/2-way pilot valve; With exhaust throttle; Incl. inspection certificate 3.1; ATEX Ex II 2G Ex h IIC T-20°C...+70°C Gb; Ex II 2D Ex h IIIC T-20°C...+70°C Db; Special version
