Special armatures

2/2-way coaxial valve; Directly operated; G1/2"; 0...40bar; 24VDC; DN15; NC; Body: Stainless steel; Medium: Hydrogen/Methane; Terminal box; Special seals; Incl. certificate for vacuum; ATEX CE Ex II 3G Ex ec IIC T3 Ta -20...+80°C Gc; CE Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc; Ex II 3G Ex h IIC T3 Gc; Ex II 3D Ex h IIIC T195°C Dc; Special version

VMK20NC-553205

2/2-way coaxial valve; G1"; 0...16bar; DN20; NC; Externally controlled; Body: Nickel plated brass; Medium: Ceramic mud; Special seals; Flushing hole; Grease nipple; Incl. mounting bracket; Special version

CVT-15-NC-422

2/2-way coaxial valve; Directly operated; G3/4"; 0...40bar; 230VAC; NC; Body: Stainless steel; Medium: Fuel 160°C; Terminal box; CE0036; TÜV: 5S252; Z-IS-TAF-MUC-25-08-2652116-20175136; Special version

CVTE-P-32-NC-020

2/2-way coaxial valve; Externally controlled; G11/2"; 0...16bar; 24VDC; DN32; NC; Body: Brass; Medium: Emulsion; Incl. 5/2-way pilot valve; Coil with connection M12x1; Special seals; Special version

CVT-15-NC-117

2/2-way coaxial valve; Directly operated; G1/2"; 0...16bar; 24VDC; DN15; NC; Body: Brass; Medium: Air -30°C; Special seals; Incl. 2 inductive NAMUR limit switches OPEN/CLOSED (I.); Incl. inspection certificate 3.1; Special version

VMK20NC-524833

2/2-way coaxial valve, G 11/4" 0-40 bar, DN 20, NC, pilot-operated Body: nickel-plated brass Medium: ceramic slip incl. special seals, grease nipple and flushing bore

CVPHB3-P-32-004

Coax-Relief valve; Externally controlled; Manually; G11/2"; 5…120bar; 24VDC; DN32; Body: Zinc plated steel; Medium Emulsion/Oil; Incl. 3/2-way pilot valve; Coil with connection M12x1; Special version

CV3T-10-NC-010

3-fold-Module block Consists of 3 Pieces CVMT-10-NC-004; 2/2-way coaxial valve; Directly operated; G3/4"; 0…40bar; 24VDC; DN10; NC; Body: Brass; Medium: Emulsion; Module block Aluminum, Connection Module block G1"; Additional thread in end plate G1" ; Incl. LED; Incl. mounting bracket; Special version

FK15NC-526919

2/2-way coaxial valve, DN15, PN16 0-16 bar, 110VAC, NC, direct-acting body: zinc-plated steel, medium: compressed air incl. terminal box and special voltage ATEX CE Ex II 2 GD c T6

FK15NC-519099

2/2-way coaxial valve, DN15, PN16 0-16 bar, 200VDC, NC, direct-acting body: zinc-plated steel, medium: heating oil incl. terminal box and special seals ATEX CE Ex II 2 GD c T6

CV3T-10-NC-003

3-fold-Module block Consists of 3 Pieces CVMT-10-NC-009; 2/2-way coaxial valve; Directly operated; Special connection G1/2"; 0…40bar; 24VDC; DN10; NC; Body: Brass; Medium: Emulsion/Grinding oil; Incl. special seals; Incl. Pin plate; Connection Module block G3/4"; Incl. Plug screw; Special version

CVTV-P-40-NC-002

2/2-way coaxial valve; Externally controlled; G11/2"; 0...16bar; 24VDC, DN40; NC; Body: Zinc plated steel; Medium: Emulsion; Incl. 5/2-way pilot valve; Coil with connection M12x1-DESINA; Special version

CVTV-P-40-NC-003

2/2-way coaxial valve; Externally controlled; G11/2"; 0...16bar; 24VDC, DN40; NC; Body: Zinc plated steel; Medium: Emulsion; Incl. 5/2-way pilot valve; Connector M12x1-DESINA; Special version

5-VMK32NC-542432

2/2-way coaxial valve, G11/4"; 0...40 bar; 24VDC; DN32; NC; Externally controlled; Body: Brass; Medium: Mineral oil; Incl. 5/2-way pilot valve ISO1; LED And Sub base ISO1; Special version

CVT-15-NC-284

2/2-way coaxial valve; Directly operated; Connection Special flange; TC14; 0...16bar; 24VDC; DN15; NC; Body: Stainless steel; Medium: Demineralized water; Incl. Terminal box; Plunger PTFE-coated; Special version

CVT-20-NC-075

2/2-way coaxial valve; G3/4"; 0...100bar; 24VDC; DN20; NC; Directly operated; Body: Brass; Medium: Hydraulic oil; Incl. LED; Special seals; Special version

CVT-20-NC-105

2/2-way coaxial valve; G3/4"; 0...100bar; 230VAC; DN20; NC; Directly operated; Body: Brass; Medium: Carbon dioxide; Incl. LED; Special seals; Special version

CVT-15-NC-221

2/2-way coaxial valve; Directly operated; G3/8"; 0...100bar; 220VDC; DN10; NC; Body: Nickel plated brass; Medium: Compressed air; Incl. LED; Incl. mounting bracket; Special version

CVT-15-NC-139

2/2-way coaxial valve; G1/2"; 0...40bar; 230VAC; DN15; NC; Directly operated; Body: Stainless steel; Medium: Hydrogen -10°C; Incl. LED; Special seals; Special version

CVTV-P-40-NC-001

2/2-way coaxial valve; G11/2"; 0...16bar; 24VDC, DN40; NC; Externally controlled; Body: Zinc plated steel; Medium: Emulsion; Incl. 5/2-way pilot valve; Incl. LED; Special version
