Special armatures

List prices MSP RO
CVFV-80-NC-002
2/2-way coaxial valve; DN80; Flange PN40; 0...40bar; DN80; NC; Externally controlled; Body: Steel nickel plated; Medium: Heavy oil; Special seals; ATEX zone 2; Special version
CVT-50-NC-025
2/2-way coaxial valve; Directly operated; 2"NPT; 0...16bar; 24VDC; DN50; NC; Body: Stainless steel; Medium: Water; Terminal box; Special seals; Incl. 1 inductive limit switch OPEN; ATEX CE Ex nA II T3 / CE Ex tc IIIC T195°C; Ex II 3G Ex h IIC T3 Gc; Ex II 3D Ex h IIIC T195°C Dc; Special version
CVFE-50-NC-004
2/2-way coaxial valve; Flange DN50; PN63; 0...63bar; NC; Externally controlled; Body: Stainless steel; Medium: Cooling water; Incl. special seals; Special version
SG09-20-WWN1253-01
Control valve Type SG09, DN20; PN10/40; NC; Material: 1.4571/1.4581; Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 3 (100%); Characteristic Equal percentage; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA; Cover sealing PTFE; Intermediate tube-Seal PTFE
SG07-50-WWC1253-03
Control valve Type SG07, DN50; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 19 (100%); Characteristic Equal percentage; Diaphragm actuator 125cm²; Mounted I/P-positioner PS2 6DR50100NG000AA0; Input signal 4-20mA
CV7TE-P-10/25-NC-001
7-fold-Module block Consists of 2 Pieces CVMTE-P-10-NC-008 (Flow direction from the valve manifold); 3 Pieces CVMTE-P-10-NC-009 (Flow direction to the valve manifold); 2 Pieces CVMTE-P-25-NC-002 (Flow direction to the valve manifold); 7x2/2-way coaxial valve; Externally controlled; 0...40bar; 24VDC; NC; Body: Brass; Medium: Helium/Air; Incl. 5/2-way pilot valve; Incl. LEDIncl. adapter plate 5x; Incl. Sensor drilling ; Special version
SG06-40-WWN80-01
Control valve Type SG06; DN40; PN10/40; NC; Material: 1.4408, Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 11 (40%), Characteristic linear; Actuator diameter 80mm; Digital positioner. Stainless steel; 4-wire; Flange; Circlip + Cap Stainless steel; Fittings and tubes made of stainless steel; Special version
SG07-65-UWC1253-05
Control valve Type SG07, DN65; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 52 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Positioner PS2 6DR5010-0EG00, ATEX EEx ia/ib IIC, IP66
CVTE-P-50-NC-002
2/2-way coaxial valve; G2"; 0...100bar; 24VDC, DN50; NC; Externally controlled; Body: Stainless steel; Medium: Hydrogen; Special seals; Incl. 5/2-way pilot valve; ATEX-design CE Ex II GD c T4; Special version
SG07-80-UWC1253-01
Control valve Type SG07, DN80; PN10/40; NC; Material: Carbon steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 92 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
SG07-65-UWF1253-05
Control valve Type SG07, DN65; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Stainless steel/SFC; Kvs-value 52 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner 4-wire 4-20mA; Position feedback 4-20 mA
BS08-65-T-B-01
Ball sector valve; Wafer type; DN65; PN25; Body 1.4408/1.4404; Ball sector 1.4408 Hard chrome plated/Lapped surface; Seat ring Stellite; Seals FKM/PTFE; KVS 190 (100%); Medium temperature -15...+200°C; Incl. Adapter set DIN/ISO5211 F07- SW17
SG10-25-WWF1252-03
Control valve Type SG10; DN25; PN10/40; NC; Material: 1.4571/1.4581; Fixed disc 1.4571 Coated; Sliding disc SFC; additional metal bellows 1.4571; Kvs-value 11 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Mounted I/P-positioner; Sipart PS2; Input signal 4-20mA; II2G Ex ia IIC T6/4 Gb; Area 1
SG12-32-UWNEC5
Sliding gate valve with electrical actuator Type SG12; DN32; PN10/40; Body: Zinc plated steel, Fixed disc STN2; Sliding disc STN2; Kvs-value 16 (100%); Characteristic linear; 100-240VAC; Incl. Position electronics
SG07-50-WWN1253-01
Control valve Type SG07, DN50; PN10/40; NC; Material: 1.4408; Fixed disc STN2; Sliding disc STN2/STN3; Kvs-value 45 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
SG17-25-WWF4/10-02
Sliding gate-pressure regulator; Controlled by own medium; Nominal pressure PN10/40; Wafer type; Material Stainless steel 1.4408; Diaphragm EPDM; Fixed disc Stainless steel AISI 316Ti coated; Sliding disc SFC; Nominal diameter 25mm; Kvs-value 5 (100%); Characteristic equal percentage; Pressure range 4...10bar; Length 33mm; Incl. equalizing tank
SG07-80-UWC1253-02
Control valve Type SG07, DN80; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 40 (40%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
SG07-80-UWC1253-03
Control valve Type SG07, DN80; PN10/40; NC; Material: Carbon steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 58 (63%); Characteristic Linear; Diaphragm actuator 125cm²; Digital positioner; 4-wire; 4-20mA
SG06-50-WWC80-01
Control valve Type SG06; DN50; PN10/40; NC; Material: 1.4408, Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 10 (20%), Characteristic linear, Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA; ATEX Zone 1
CVFE-P-40-N0-002
2/2-way-coaxial valves; Externally controlled; Flange DN40; ANSI600; Pressure range 0...63bar; NO; Body: Stainless steel; Medium: Demineralized water; Incl. 5/2-way pilot valve 125VDC; Incl. LED; Special seals; 1 x Preparation for limit switch; Incl. certificate 2.2; Special version
