Special armatures

2/2-way coaxial valve; Externally controlled; G1"; 0...200bar; DN25; NC; Body: Stainless steel; Medium: Water/Sodium hydroxide solution 80°C; Special seals; Mounting bracket; Flow control valves;Special version

CVFV-40-NC-005

2/2-way coaxial valve; Externally controlled; Flange DN40; PN40; 0...16bar; NC; Body: Stainless steel; Medium: Oil; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Special version

CVF-50-N0-020

2/2-way coaxial valve; Directly operated; Flange PN16 DN50; 0...16bar; 24VDC; NO; Body: Steel nickel plated; Medium: Hydrogen 80°C; Terminal box; Incl. mounting bracket; Back pressure tight; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Cable 10m; Vacuum leak test with certificate; CE-Marking; ATEX CE Ex II 3G Ex ec IIC T3 Ta -20...+80°C Gc / CE Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc; Ex II 3G Ex h IIC T3 Gc / Ex II 3D Ex h IIIC T195°C Dc; Incl. test report 2.2; Incl. inspection certificate 3.1; Special version

SG06-25-UWC80-02

Control valve Type SG06; DN25; PN10/40; NC; Material: Carbon steel, Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 11 (100%), Characteristic linear, Actuator diameter 80mm; Digital positioner; 4-wire; 4-20mA; Feedback module with 2 integrated limit indicators RM5

CVT-40-NC-040

2/2-way coaxial valve; Directly operated; G2"; 0...63bar; 24VDC; DN40; NC; Body: Stainless steel; Medium: Hydrogen; Terminal box; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED (B.); Incl. inspection certificate 3.1; Vacuum-test with certificate; ATEX CE Ex nA II T3 / CE Ex tc IIIC T195°C; Ex II 3G Ex h IIC T3 Gc; Ex II 3D Ex h IIIC T195°C Dc; Free of oil and grease; Special version

8040-GS1-065-4041029

065VB0101M------M6 GS shut-off valve type 8040 DN65 wafer body PN10-40, body made of stainless steel 1.4571, fixed sealing disc made of stainless steel 1.4571 coated, moving disc made of carbon material with metallic impregnation

8044-GS1-050-4073065

050VE0101M----6-ZC-S--1: GS1 control valve DN50 PN10/40 NC body 1.4571 sliding pair Standard KV10 (20%) characteristic linear actuator D80 incl. digital positioner 8049 4-wire input signal 4-20 mA oil- and grease-free version for oxygen

8044-GS1-050-4041995

050VE0102M------Z8-S6-1 GS1 control valve, DN50, PN10/40, NC body 1.4571, sliding pair Standard KV45 (100%), characteristic linear, actuator D125 incl. positioner 8047, 2-wire, 4-20mA, oil- and grease-free for oxygen

8020-GS1-065-4001813

065VP0113 GS1 control valve,8020, wafer,NO DN065, PN10/40, body 1.4571/1.4581 sliding pair standard, KV 52 (100%), characteristic linear actuator 125 cm²

CVF-50-NC-018

2/2-way coaxial valve; Directly operated; Flange DN50 PN16; 0...16bar; 230VAC; NC; Body: Zinc plated steel; Medium: Hydrogen; Special seals; ATEX II 3G Ex h IIC T3 Gc AndII 3D Ex h IIIC T195°C Dc; incl. 4 inductive NAMUR limit switches OPEN/CLOSED (2xOpen, 2xClose, B.); Special version

SG07-50-UWC1253-04

Control valve Type SG07, DN50; PN10/40; NO; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 28 (63%); Characteristic Linear; Diaphragm actuator 125cm²; Incl. Coupler For positioner Eckardt, ABB-TZID/TZID-C, Siemens-PS2, Samson-3730/DVC2000

SG18-65-UWC-EC8-01

Control valve with electrical actuator Type SG18; DN65; PN10/40; Body: carbon steel 1.0619/1.0570, Fixed disc Stainless steel AISI 316Ti Coated; Sliding disc Carbon; Kvs-value 52 (100%); Characteristic linear; 0,9kn, 230VAC; Incl. 2 mechanical limit switches OPEN/CLOSED; Feedback via potentiometer 1000 Ohm

CVFV-P-125-NC-001

2/2-way coaxial valve; Externally controlled; Flange DN125 PN16; 0...16bar; 24VDC; NC; Body: Aluminum; Medium: Emulsion; Incl. 5/2-way pilot valve; Incl. LED; Special version

CVF-15-N0-012

2/2-way coaxial valve; High temperature design; Directly operated; Flange PN100; Pressure range 0...63bar; 220VDC; DN15; NO; Body: Stainless steel; Medium: Natural gas +210°C; Terminal box; Incl. Mounting bracket; Special seals; Incl. 2 inductive limit switches (B.HT); 2x Position CLOSED; 2x Preparation for limit switch; CE0036-Mark; ATEX Ex II 3G Ex ec IIC T3 Ta -20...+80°C Gc / Ex II 3D Ex tc IIIC T195°C Ta -20...+80°C Dc; Ex II 3G Ex h IIC T3 Gc / Ex II 3D Ex h IIIC T195°C Dc; Incl. inspection certificate 3.1; Material certificate; Z-IS-TAF-MUC-16-06-2652116-008-Rev.01; Special version
