Special armatures

List prices MSP RO
CVF-25-NC-072
2/2-way coaxial valve; Directly operated; Flange ANSI-RF 150 lb ; 0…16bar; 24VDC; DN25; NC; Body: Stainless steel; Medium: Turbine oil 93°C; Incl. Terminal box; Incl. 2 limit switches OPEN/CLOSED GO-Switch; UL/CSA - approval; Material certificate; Special version
8020-GS1-100-4063983
100VP0004M- - 91 GS1 control valve, DN100, NC PN 10-40, housing steel, sliding pair STN2 KV 154 (100%), linear, actuator 250
CVFV-100-NC-002
2/2-way coaxial valve; Externally controlled; Flange PN40; 0...16bar; DN100; NC; Body: Steel nickel plated; Medium: Hot air +160°C; Control port G3/8"; Special seals; Special version
CVFEH-P-50-NC-001
2/2-way coaxial valve; Externally controlled; Flange DN50; PN250; 0...200bar; 24VDC; NC; Body: Zinc plated steel; Medium: Nitrogen; Incl. 5/2-way pilot valve; Incl. LED; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED; Special version
CVFE-50-NC-001
2/2-way-coaxial valves; Externally controlled; NC; Stainless steel; DN 50mm; Flange ANSI-RF 600lb; Pressure range 0...63bar; Medium; Special seals; Special flanges; Special version
8020-GS1-065-4064179
065VP0103M4-91--Z-MS----14 GS1 control valve, 8020, wafer, NC DN065, PN10/40, body 1.4571/1.4581 KV 52 (100%), characteristic linear sliding pair STN2/STN3, actuator 125 cm² (8 springs) incl. inductive limit signal switch M12x1 DC 10-30V PNP with plug connection, mounted in clamping sleeve M16x1 positioner settings: split range (2-11mA) inverse function special versions: degrease individual parts of lower section, sealing and guide parts greased with grease SYN-setral/250 S (for oxygen)
8021-GS1-065-4064179
065VP0103M4-91--Z-MS----14 GS1 control valve, DN65, PN10/40, NC body stainless steel 1.4571/1.4581, sliding pair STN2 actuator D125, KVS52(100%), characteristic linear 2 inductive limit signal switches M12x1 DC 10-30V PNP with plug grub screws and adjusting nut secured
VSV-F80NC-541826
2/2-way coaxial valve, DN 80, 3" ANSI-RF 150 lbs, 0-16 bar, NC, pilot-operated body: zinc-plated steel, medium: heating oil 135°C hydraulic actuation, 105 bar, special actuator special seals, special flanges, special control port limit switch preparation, works certificate 2.2, 1x limit switch preparation for GO-Switch (indication: closed) special flushing bore connection, suitable for Atex Zone 1
SE35-T25-ZP1253
Aseptic valve; Angle type; NC; Material: 1.4435 Polished RA<0,6µm, Control cone PEEK; Diaphragm EPDM/PTFE; Tri-clamp according to inch; DN 25mm; Kvs-value 8,8 (100%), Characteristic linear, Actuator diameter 125mm; Medium temperature -20...+140°C; Operating pressure 0...14bar; EHEDG Certificate
SG07-100-UWF1254-02
Control valve Type SG07; DN100; PN10/40; NC; Material: Zinc plated steel; Fixed disc 1.4571 Coated; Sliding disc SFC; Kvs-value 154 (100%); Characteristic Linear; Diaphragm actuator 125cm², Spring configuration 4 (8 Springs); P/P-positioner 0.2-1bar
SG24-50-SWC125-01
Sliding gate-shut off valve; High temperature design; Type SG24, DN40; PN10/25/40; NC; Housing material: 1.4571/1.4581; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 26 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Medium temperature -60…+450°C; 2x Inductive position indicator M12x1 10-30VDC PNP
SG24-50-SWC125-02
Sliding gate-shut off valve; High temperature design; Type SG24, DN40; PN10/25/40; NO; Housing material: 1.4571/1.4581; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 26 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Medium temperature -60…+450°C; 2x Inductive position indicator M12x1 10-30VDC PNP
CVFV-80-NC-003
2/2-way coaxial valve;Externally controlled; ANSI300; 0...40bar; DN80; NC; Externally controlled; Body: Zinc plated steel; Medium: Nitrogen/Vacuum; Vacuum-test with certificate; Incl. 2 inductive limit switches (I.); Incl. inspection certificate 3.1; Special version
VSVF65NC-522153
2/2-way coaxial valve, DN65, PN64 0-64 bar, NC, pilot-operated Body: zinc-plated steel, Medium: native oil special seal
5-VMKH25NC-500473
2/2-way coaxial valve; G1"; 0...200bar; 24VDC, DN25; NC; Externally controlled; Body: Stainless steel; Medium: Deionate; Incl. 5/2-way pilot valve; LED; Special seals; Incl. mounting bracket; Incl. 1 inductive limit switch Position CLOSED; Incl. inspection certificate 3.1; Special version
5-VMKH25NC-538102
2/2-way coaxial valve; G1"; 0...200bar; 24VDC, DN25; NC; Externally controlled; Body: Stainless steel; Medium: Demineralized water/Heating oil; Incl. 5/2-way pilot valve; LED; Special seals; Incl. mounting bracket; Incl. 1 inductive limit switch Position CLOSED; Incl. inspection certificate 3.1; Special version
8020-GS3-040-4062145
040VPH113M--91--Z--S----79 GS3 control valve,8020,wafer,NO DN40, PN100, body 1.4571 / 1.4581 KVS26(100%), characteristic linear, sliding pairing STN2 incl. i/p positioner type 3730-2 Ex, IP65
CVF-50-NC-006
2/2-way coaxial valve; Directly operated; Flange PN16 DN50; 0...16bar; 24VDC; NC; Body: Stainless steel; Medium: Sodium hydroxide solution; Incl. LED; Special seals; Incl. 2 inductive limit switches OPEN/CLOSED (I.); Special version
SG02-125-UWCW
Manual control valve Type SG02; DN125; PN10/40; Body: Zinc plated steel, Fixed disc 1.4571 Coated; Sliding disc Carbon; Kvs-value 237 (100%)
SG07-80-WWC1253-02
Control valve Type SG07, DN80; PN10/40; NC; Material: 1.4408; Fixed disc 1.4571 Coated; Sliding disc Carbon material; Kvs-value 92 (100%); Characteristic Linear; Diaphragm actuator 125cm²; Without Digital positioner
