Pressure regulator

NSF-approved; Body Fibre-glass-reinforced polyamide Grivory GV-5 FWA; Seals EPDM-FDA; Maximum inlet pressure 15bar; Medium temperature +4…+60°C; Flow at Δp=0,8bar 10l/min

Body Brass; Fine screen Stainless steel; Spring cover, Screen cup Polyamide; Seals NBR/EPDM; Mesh size 0,5mm; Max. Inlet pressure 30bar; Operating pressure range 1,5...6bar; Medium temperature -10…+70°C

Body Bronze; Fine screen Stainless steel; Seals EPDM; Maximum inlet pressure 25bar; Operating pressure range 0,5...2bar; Medium temperature -20...+120°C

Without relieving; Body Bronze; Maximum inlet pressure 60bar

Body Bronze; Fine screen Stainless steel; Seals EPDM; Maximum inlet pressure 40bar; Operating pressure range 5...15bar; Medium temperature -20…+95°C

Body Bronze; Fine screen Stainless steel; Spring cover, Seals FKM; Max. Inlet pressure 40bar; Operating pressure range 1...8bar; Medium temperature -10…+120°C

Body Bronze; Flange PN16; Fine screen Stainless steel; Seals EPDM; Max. Inlet pressure 16bar; Medium temperature -20…+120°C

Body Ductile iron EN-GJS-400-15; Seals EPDM; Flange PN16; Max. Inlet pressure 16bar; Operating pressure range 0,5…2bar; Medium temperature -10…+60°C

Body Bronze; Flange PN40; Fine screen Stainless steel; Seals EPDM; Maximum inlet pressure 40bar; Operating pressure range 1...8bar; Medium temperature -20…+120°C

Body 1.4408; Seals FKM; Medium temperature -10…+120°C

Body 1.4408; Seals FKM; Maximum inlet pressure 40bar; Operating pressure range 5...15bar; Medium temperature -10…+95°C

Body 1.4301; 11/2"...2" 1.4571; Inner parts 1.4571; Medium temperature -20…+200°C
