BUW6-150-DSW-0G2

Butterfly valve with bare shaft Series BUW1-DSW-B, BUW2-DSW-B, BUW6-DSW-B, BUWC-DSW-B, BUWV-DSW-B, BUWZ-DSW-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner EPDM White; Medium temperature -10...+130°C; DN 150mm; Length 56mm; Pressure range 0...16bar; Flange PN10/16/ANSI150

Electrical actuator Series VB; Suitable for Valves with 90° operation; For a maximum of 100 operations a day; Limit switch-off is wired; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Torque 190Nm; Operating time 27s; Flange ISO5211 F07/F10-Stern 17 mm; Voltage 100-240VAC; Protection class IP67

Adapter For butterfly valve DN40-DN150; F07/F07

Square adapter Series VK; 17X14; Length 17mm; Material Stahl
