BRI001

BRI001

STASTO Combination
Fully assembled and tested
Consists of:
Enclosure 400x1600x400;
1x Filter regulator FR12-20-08-R-PE-SS;
6x 5/2-way valve K52P2018-230VAC;
12x Manometer MA041-63R-6
12x Bulkhead fitting;
Mounting I/P-Converter;
Fully assembled and tested;
Without Electrical connections

Intrastat No.: 84123100
Country of origin: Austria
Weight: 73.017 Kg
Short Itemnumber: BRI001
https://www.stasto.ro/web/image/product.template/145225/image_1920?unique=351c77c

STASTO combination
fully assembled and tested
consists of:
enclosure 400x1600x400;
1x filter regulator FR12-20-08-R-PE-SS;
6x 5/2-way valve K52P2018-230VAC;
12x manometer MA041-63R-6
12x bulkhead fitting;
mounting I/P-converter;
fully assembled and tested;
without electrical connection

999.999,00 lei 999999.0 RON 999.999,00 lei

Not Available For Sale

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
TSRM-A-400/16-01
TSRM-A-400/16-01 x 1.0
TSRM-A-400/16-01
Schaltschrank; 400mm x 1600mm x 400mm (B/H/T); inkl. Rückwand; inkl. 2 Stück Seitenwand; inkl. Sockel 100mm
Add to Cart
5/2-way valve K52P2018
K52P2018 x 6.0
5/2-way valve K52P2018
5/2-way valve Series K5.P; Pressure range 1...9bar; Actuation Pneumatic/pneumatic; Connection 1/8"; DN 6mm; Flow rate 690Nl/min; Suitable silencer SLN-RB
Add to Cart
3/2-way valve PS125-18-C
PS125-18-C x 12.0
3/2-way valve PS125-18-C
3/2-way valve Series PS125; Directly operated; Battery valve, Optional expandable; Actuation Electrical/spring; Standard coil C001; Connector size 22mm; Connection 1/8"; Nominal diameter 1,2mm; Function NC; Pressure range 0…10bar; Flow rate 90Nl/min
Add to Cart
MA041-63R-6
MA041-63R-6 x 12.0
MA041-63R-6
Glycerin manometer; Bourdon tube manometer; Body Stainless steel, Front ring 3-square Chromium-plated; Mounting clamp; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection 1/4" Rear; Class 1,6; Diameter 63mm; Indicating range 0-6; Unit bar
Add to Cart
Filter regulator FR-12-20-08-R-PE-SS
FR-12-20-08-R-PE-SS x 1.0
Filter regulator FR-12-20-08-R-PE-SS
Filter regulator Series FR01/FR; Relieving; Drain valve Semi-automatic; Pressure range 0,5...8bar; Filter element 20µm; Plastic bowl with protection cage; Connection 1/2"; Flow at 6,3bar/Δp=1bar 2880Nl/min; Max. inlet pressure 12,5bar
Add to Cart
Silencer SLN-M18-RB
SLN-M18-RB x 12.0
Silencer SLN-M18-RB
Silencer Series SLN-RB; Sinterbronze; Thread Steel copper plated; Operating pressure Max. 16bar; Connection 1/8"; Length 23mm
Add to Cart
Plug screw 1/8"
TH50-18-N-0 x 11.0
Plug screw 1/8"
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/8"
Add to Cart
Plastic hose CP-10/8-BU-1
CP-10/8-BU-1 x 1.0
Plastic hose CP-10/8-BU-1
Plastic hose Series CP; Material Co-polyurethane; Multiplier for operating pressure 30°C = 0,87 / 80°C = 0,40; Vacuum -0,87bar; Temperature range -40...100°C; Outside diameter 10mm; Inside diameter 8mm; Operating pressure at 23°C 11bar; Colour blau
Add to Cart
Plastic hose CP-6/4-BU-1
CP-6/4-BU-1 x 44.0
Plastic hose CP-6/4-BU-1
Plastic hose Series CP; Material Co-polyurethane; Multiplier for operating pressure 30°C = 0,87 / 80°C = 0,40; Vacuum -0,87bar; Temperature range -40...100°C; Outside diameter 6mm; Inside diameter 4mm; Operating pressure at 23°C 18bar; Colour Blue
Add to Cart
09120205070
09120205070 x 2.0
09120205070
Hexagon socket-Mounting screws; Suitable for Cetop Solenoid valves; According to DIN 912; Property class 10.9; Thread M5x70; Valve-Nominal size 06; Tightening torque 8,9Nm
