BEE-001

BEE-001

STASTO automation package, BJ-06 Beta


Weight: 3.997 Kg
Short Itemnumber: BEE001
https://www.stasto.ro/web/image/product.template/106675/image_1920?unique=d0d277a

999.999,00 lei 999999.0 RON 999.999,00 lei

Not Available For Sale

  • Function
  • Design
  • Actuator
  • Brand

This combination does not exist.

Availability:
Contact Us

Share

Brand STASTO
21JP1R1V23-T0
21JP1R1V23-T0 x 5.0 Pcs
21JP1R1V23-T0
2/2-way solenoid valve; Directly operated; NC; Body PPS; Tube Stainless steel; Seal FKM; Medium temperature -10...+120°C; Standard coil LBA; Connector size 22mm; G 1/8"; DN 2,3mm; Pressure AC 0-15bar; Pressure DC 0-8bar; Length 34mm; NSF-certificate
LBA05024CS x 5.0 Pcs
LBA05024CS
Coil Type LBA; Connector size 22mm; Voltage 24VDC
3/2-way valve K32W1S618
K32W1S618 x 2.0 Pcs
3/2-way valve K32W1S618
3/2-way valve Series K3.W; Pilot-operated; Pressure range 2,5...9bar; Actuation Electrical/spring; Type of coil CS; Connector size 16mm; Connection 1/8"; Nominal diameter 6mm; Function NC; Flow rate 730Nl/min; Suitable silencer SLN-RB
CS02400
CS02400 x 2.0 Pcs
CS02400
Coil Type CS; Connector size 16mm; Voltage 24VDC
Plug screw 1/8"
TH50-18-N-0 x 1.0 Pcs
Plug screw 1/8"
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/8"
2/2-way solenoid valve 21A3ZV30
21A3ZV30 x 1.0 Pcs
2/2-way solenoid valve 21A3ZV30
2/2-way solenoid valve Series 21A; Directly operated; NO; Body Brass; Tube Stainless steel One-piece; Seal FKM; Medium temperature -10...+120°C; Connector size 32mm; G 1/8"; DN 3mm; Pressure AC/DC 0-10bar; Length 40mm; Standard coil BDA
BDA08024CS
BDA08024CS x 1.0 Pcs
BDA08024CS
Coil Type BDA; Standard; Connector size 32mm; Voltage 24VDC
Check valve MV23-00-18
MV23-00-18 x 2.0 Pcs
Check valve MV23-00-18
Check valve Series MV23; Axial type; Female thread; Nickel plated brass; Pressure range 0,2...10bar; Connection 1/8"; Flow rate 900Nl/min; Length 36,5mm
Pressure regulator PR22-18-0,2/4
PR22-18-0,2/4 x 1.0 Pcs
Pressure regulator PR22-18-0,2/4
Pressure regulator Series PR22; Body POM Food safe; Inner parts Stainless steel AISI 316; Seals EPDM/NBR Food safe; Max. Inlet pressure 16bar; Medium temperature +5...23°C; G 1/8"; Pressure range 0,2…4bar
Compact magnetic cylinder NSKU40-80-M
NSKU40-80-M x 1.0 Pcs
Compact magnetic cylinder NSKU40-80-M
Compact magnetic cylinder Series NSKU-M; Double acting; According to Unitop Standard; Pressure range 1...10bar; Piston rod with male thread; Diameter 40mm; Stroke 80mm; Piston rod thread M10x1,25; Connection 1/8"; Push force at 6 bar 754N
Lock nut U-25
U-25 x 1.0 Pcs
Lock nut U-25
Lock nut Series U; For piston rod; For cylinder; Thread M10x1,25; Diameter Series DVM, ACM 25mm; Diameter Series NSKU-M 20, 25, 32, 40mm
Rod clevis G-32
G-32 x 1.0 Pcs
Rod clevis G-32
Rod clevis Series G; For cylinder; Thread M10x1,25; Diameter Series NWT, RWS, ACMT-ISO 32mm; Diameter Series NSKU-M 20, 25, 32, 40mm
BEE-003 x 6.0 Pcs
BEE-003
3/2-way valve, direct operated, actuation electric/spring, 24VDC without plug, plug width 22mm, connection 1/8", nominal size 1,2mm, function NC, incl. 2 T-pieces 8mm and straight screw-in fitting 6mm, fully assembled and tested
Cartridge cylinder CZ16-15T
CZ16-15T x 6.0 Pcs
Cartridge cylinder CZ16-15T
Cartridge cylinders Series CZ; Single acting; Pressure range 2...7bar; Connection M5, Female thread; Diameter 16mm; Stroke 15mm; Piston rod thread M5; Mounting thread M22x1,5; Push force at 6 bar 102N
Silencer SLS-MM5-BS
SLS-MM5-BS x 6.0 Pcs
Silencer SLS-MM5-BS
Silencer Series SLS-NS; Operating pressure Max. 12bar; Connection M5; Length 9mm; Body Messing; Screen Edelstahl
Silencer SLS-M18-PS
SLS-M18-PS x 2.0 Pcs
Silencer SLS-M18-PS
Silencer Series SLS-PS; Body Plastic Polyamide, Screen Stainless steel; Operating pressure Max. 12bar; Connection 1/8"; Length 15mm
Unidirectional banjo flow control valve UFC05-V-18-18F
UFC05-V-18-18F x 1.0 Pcs
Unidirectional banjo flow control valve UFC05-V-18-18F
Unidirectional banjo flow control valve Series UFC05-C/V; Banjo with female thread; Actuation Slotted screw/Knurled screw fixable; Connection 1/8"; Direction of flow control From banjo to thread (ingoing air)
Unidirectional banjo flow control valve UFC05-C-18-18F
UFC05-C-18-18F x 2.0 Pcs
Unidirectional banjo flow control valve UFC05-C-18-18F
Unidirectional banjo flow control valve Series UFC05-C/V; Banjo with female thread; Actuation Slotted screw/Knurled screw fixable; Connection 1/8"; Direction of flow control From thread to banjo (outgoing air)
