Flanged ball valve with pneumatic actuator Series BADA Store
  1. Products
  2. Armatures
  3. Ball valves - automatically operated
  4. Flanged ball valves - pneumatically operated
  5. Flanged ball valve with pneumatic actuator Series BADA
  6. BADA-125-CITV-S0-ABS53-C001-03-C002-31-6-EB0X01-WSTHVB
BADA-125-CITV-S0-ABS53-C001-03-C002-31-6-EB0X01-WSTHVB
BADA-125-CITV-S0-ABS53-C001-03-C002-31-6
BADA-125-CITV-S0-ABS53-C001-03-C002-31-6
16.294,50 lei
16.294,50 lei
BADA-125-CITV-S0-ABS53-C001-03-C002-31-LV-2
BADA-125-CITV-S0-ABS53-C001-03-C002-31-LV-2
16.322,00 lei
16.322,00 lei

BADA-125-CITV-S0-ABS53-C001-03-C002-31-6-EB0X01-WSTHVB

BADA-125-CITV-S0
flanged ball valve with pneumatic actuator series BADA; flange PN16; body steel; ball AISI 304; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...16bar; nominal diameter 125mm; length 196mm; actuator PAS1605
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X01-WSTHVB
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic; mounting bridge stainless steel

Intrastat No.: 84818081
Country of origin: Italy
Weight: 71.76 Kg
Short Itemnumber:BADA125CITVS0ABS53C00103C002316EB0X01WSTHVB
https://www.stasto.ro/web/image/product.template/232857/image_1920?unique=d9024cc

BADA-125-CITV-S0
flanged ball valve with pneumatic actuator series BADA; flange PN16; body steel; ball AISI 304; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...16bar; nominal diameter 125mm; length 196mm; actuator PAS1605
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X01-WSTHVB
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic; mounting bridge stainless steel

16.923,80 lei 16923.8 RON 16.923,80 lei

Not Available For Sale

  • Attachment interface VDI/VDE 3845
  • Attachment interface 2 VDI/VDE 3845
  • Valve interface Namur
  • DN
  • Length
  • Connector size
  • Switch type
  • Design
  • Voltage
  • Switching capacity
  • Pressure range
  • Contact material
  • Material of case
  • Coil
  • Actuator
  • Actuator 2

This combination does not exist.

Availability:
Contact Us
dimension
Valve interface Namur 1/4"
DN 125 mm
Length 196 mm
Designs
Connector size 22
design
Design Standard
Electrical key figures
Voltage 24VDC / 48V/50-60Hz
pressure
Pressure range 0...16 bar
characteristics
Coil C001
Actuator PAS1605
