Flanged ball valve with pneumatic actuator Series BADA Store
  1. Products
  2. Armatures
  3. Ball valves - automatically operated
  4. Flanged ball valves - pneumatically operated
  5. Flanged ball valve with pneumatic actuator Series BADA
  6. BADA-025-CITV-D0-ABS51-C001-03-C002-31-6-EB0X01
BADA-025-CITV-D0-ABS51-C001-03-C002-31-6-EB0X01
BADA-025-CITV-D0-ABS51-C001-03-C002-31-6
BADA-025-CITV-D0-ABS51-C001-03-C002-31-6
3.097,20 lei
3.097,20 lei
BADA-025-CITV-D0-ABS51-C001-03-C002-31-LV-2
BADA-025-CITV-D0-ABS51-C001-03-C002-31-LV-2
3.124,80 lei
3.124,80 lei

BADA-025-CITV-D0-ABS51-C001-03-C002-31-6-EB0X01

BADA-025-CITV-D0
flanged ball valve with pneumatic actuator series BADA; flange PN16; body steel; ball AISI 304; seals PTFE/FKM; double acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...16bar; nominal diameter 25mm; length 46mm; actuator PAD052
ABS51
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X01
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic

Intrastat No.: 84818081
Country of origin: Italy
Weight: 4.888 Kg
Short Itemnumber:BADA025CITVD0ABS51C00103C002316EB0X01
https://www.stasto.ro/web/image/product.template/226525/image_1920?unique=d9024cc

BADA-025-CITV-D0
flanged ball valve with pneumatic actuator series BADA; flange PN16; body steel; ball AISI 304; seals PTFE/FKM; double acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...16bar; nominal diameter 25mm; length 46mm; actuator PAD052
ABS51
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 5/2-way solenoid valve - NAMUR type (NM52W1S-PR); actuator PAD052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X01
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831613; contact material silver-nickel; material of case plastic

3.616,90 lei 3616.9 RON 3.616,90 lei

Not Available For Sale

  • Attachment interface VDI/VDE 3845
  • Attachment interface 2 VDI/VDE 3845
  • Valve interface Namur
  • DN
  • Length
  • Connector size
  • Switch type
  • Design
  • Voltage
  • Switching capacity
  • Pressure range
  • Contact material
  • Material of case
  • Coil
  • Actuator

This combination does not exist.

Availability:
Contact Us
dimension
Attachment interface VDI/VDE 3845 80x30x20
Attachment interface 2 VDI/VDE 3845 80x30x30
Valve interface Namur 1/4"
DN 25 mm
Length 46 mm
Designs
Connector size 22
Switch type Crouzet 831613
design
Design Standard
Electrical key figures
Voltage 24VDC / 48V/50-60Hz
Switching capacity 4A/250VAC-1A/24VDC
pressure
Pressure range 0...16 bar
materials
Contact material Silver-nickel
Material of case Plastic
characteristics
Coil C001
Actuator PAD052
