Ball valve made of stainless steel Series BA469-LLD-A; ATEX II 2 G/D; Fire-Safe; Full bore; Two-parts type; Female thread; Body, Ball 1.4404; Seals PTFE Reinforced with carbographite; Medium temperature -20...+160°C; Nominal diameter 25mm; Pressure range 0...138 bar; Connection RP 1"; Length 105mm; Free of oil and grease; Class 800; With locking device
Country of origin: Italy
Short Itemnumber: BA46910LLDA
ball valve made of stainless steel series BA469-LLD-A; ATEX II 2 G/D; Fire-Safe; full bore; two-parts type; female thread; body, ball AISI 316L; seals PTFE reinforced with carbographite; medium temperature -20...+160°C; nominal diameter 25mm; pressure range 0-138bar; connection RP 1"; length 105mm; free of oil and grease; Class 800; with locking device
Technical specifications
| Pressure range | 0...138 bar |
|---|---|
| Connection | RP 1" |
| DN | 25 mm |
| Length | 105 mm |
| Pressure range | 0...138 bar |
| Connection | RP 1" |
| DN | 25 mm |
| Length | 105 mm |
| Female thread | RP 1" |
| Design | ATEX |
BA469-10-LLD-A
